Introduction
External Locator - Bottom View
Figure 6
Bottom View
1. Vent/Fan Intake
2. CPU/RAM Cover
3. Battery
4. Hard Disk/WLAN
Module/Bluetooth
Module Cover
Note: The RAM and
optional
Wireless
LAN module are lo-
cated under the CPU
Heatsink Cover.
1 - 8 External Locator - Bottom View
2
1
1
3
To prevent your computer from overheating make sure nothing blocks the vent/fan
intakes while the computer is in use.
1
4
Overheating
