CUBE Aux Send
3.1
Automation
CUBE Panner
3.1
Automation

Abs vs. Trim

i d t
Euphonix CS3000/2000 MixView 3.2 Software Supplement
Console automation covers dynamic level and mute capabilities of the first
twelve (1-12) Aux Sends provided by the Audio CUBE. The "idt" automation
status LEDs operate identically to dynamic EQ automation. However, unlike
EQ, the CUBE also allows automation in Trim as well as Absolute, Win, Wout
and MBR (Monitor Before Record). SnapShot automation is still possible for
Aux Sends 13-48 although they are not dynamically automatable.
Punch key for level
Punch key for mute
MixView allows dynamic automation of the first eight (8) Panners provided by
the Audio CUBE. The following list and graphic details which panner param-
eters can be automated:
• Front Pan
• Front Focus
• Front Div
• Surround
• Rear Pan
• Panner Level
• Boom Level
When automating Panners in Abs mode, the yellow PanBall indicator in the
Panner screen shows the position of the
audio within the
four-quadrant
Green PanBall
panning space. In
indicator
subsequent automa-
tion passes, audio
Yellow PanBall
position from the
indicator
underlying automa-
tion data is shown by a green PanBall
indicator, allowing you to see the
relative positions of both the old and new positions as you are writing the new
automation. A red PanBall indicator signifies that the current and underlying
audio positions are nulled (i.e., occupy the same position).
In Abs mode, the "d" portion of the idt
LEDs will light. In Trim
mode, the "t" LED will
light and the associ-
ated DSC MixView
screen knobs turn green.
Section 2: Monitoring Enhancements
i d t i d t
i d t i d t
Red PanBall
indicator
1 - 19
