Section 2: Monitoring Enhancements

Automation Glide

3.1
Pnch
Fader Name Menu
Touch
F1
SIDE NOTE:
Desk Glide operates only on Fader
Objects. All other desk Objects are
unaffected when Glide is active.
Desk Glide only operates in ABS
(Absolute) Mode. Glide is inactive
whenever a fader is in Trim Mode.

Desk Automation Glide

3.2
3.1

CUBE Automation Glide

1 - 18
Glide allows for automated, seamless punch-outs of automation over a user
specified time interval. In Glide mode, any punch-out will terminate write
mode and return to read gradually by "gliding" from the last write level to the
automation level corresponding to the previously recorded underlying automa-
tion level, over the glide time interval. It is important to understand that after
you punch-out, the automation data continues to be written for the glide time
interval. The software generates the required data to connect the old and new
automation levels. When the object's automation data level reaches the
underlying automation level, the object will then be punched out. If you punch
the object in again while the glide is in progress, the glide is aborted and you
again have control of the object.
The Glide feature is activated by pressing the DSC [Glide] key. Make sure that
there is a Title loaded and the DSC [Mix On] and [Fader A] keys are lit. To set
Rel Tplt Setup
F2 F3 F4
Desk: 150
F1 F2
the Glide times, press the DSC [Pnch] key, [F4] (Setup) and then [F3] (Glide):
The Glide feature is available on Upper and Lower Desk Fader objects as well
as CUBE Aux Send and Panner objects. Press [F1] (Desk) to set the glide time
for fader objects or [F3] (Cube) to set the glide time for CUBE objects. The
SpinKnob can be used to adjust the time values in single frame increments
from 1-999. Alternatively, the DSC Numeric Keypad can be used to enter a
specific value within the same range. Entering a value via the Numeric Keypad
locks out changes via the SpinKnob. This lockout is indicated by a small
rectangle next to the current SmartDisplay key designator as shown in the
previous menu figure for F1 (Desk). Press the [Enter] key to commit the
settings. Now let's take a look at how to use the Glide feature.
With the [Glide] key lit, just punch-in and out as you normally would during a
standard automation pass. When you punch-out, glide will write a linear
automation move, for the designated period of time set in the Glide menu, to a
point where it seemlessly joins with underlying automation and punches out.
CUBE Glides operate in the same manner as Desk Glides, except that CUBE
Glide additionally supports the TRIM automation mode.
Euphonix CS3000/2000 MixView 3.2 Software Supplement
Filtr Wthru Glide
F1 F2 F3
Cube: 150
F3 F4
Auto
F4
