1-Port 10-Gigabit Ethernet SPA Overview

1-Port 10-Gigabit Ethernet SPA LEDs

The 1-Port 10-Gigabit Ethernet SPA has two LEDs, an ACTIVE/LINK LED for the port and a STATUS
LED, as shown in
Figure 3-23
1
Table 3-27
Table 3-27
LED Label
ACTIVE/LINK
STATUS
1-Port 10-Gigabit Ethernet SPA XFP Optical Transceiver Modules, Connectors,
and Cables
The 1-Port 10-Gigabit Ethernet SPA supports the following types of optical transceiver modules:
•
•
•
•
Cisco Systems qualifies the optics that are approved for use with its SPAs. As of Cisco IOS XR
Release 3.4.1, the above-listed small form-factor pluggable (XFPs) are the only optical transceiver
modules qualified for use.
Use a single-mode optical fiber that has a modal-field diameter of 8.7 ±0.5 microns (nominal diameter
is approximately 10/125 microns) to connect your router to a network.
Figure 3-24
10-Gigabit Ethernet SPA.
Cisco CRS-1 Carrier Routing System SIP and SPA Hardware Installation Guide
3-40
Figure 3-23.
1-Port 10-Gigabit Ethernet SPA Faceplate
1
ACTIVE/LINK LED
describes the 1-Port 10-Gigabit Ethernet SPA LEDs.
1-Port 10-Gigabit Ethernet SPA LEDs
Color
Off
Green
Amber
Off
Green
Amber
Single-mode short-reach (SR) XFP module—XFP-10GLR-OC192SR
Single-mode intermediate-reach (IR) XFP module—XFP-10GER-OC192IR
Single-mode very-long-reach (ZR) XFP module—XFP-10GER-OC192LR
Multi-mode short reach (SR) XFP module—XFP-10G-MM-SR
shows the cable type for use with the XFP optical transceiver module on the 1-Port
Chapter 3
2
STATUS LED
State Meaning
Off Port is not enabled by software.
On Port is enabled by software and the link is up.
On Port is enabled by software and the link is down.
Off SPA power is off.
On SPA is ready and operational.
On SPA power is on and good, and the SPA is being configured.
Overview: Cisco CRS-1 Shared Port Adapters
SPA-1X10GE-L-V2
2
OL-17439-01
