5-Port Gigabit Ethernet SPA Overview

1-Port OC-192c/STM-64 POS/RPR VSR Optics SPA Fixed Optical Transceiver,
Connector, and Cables
The 1-Port OC-192c/STM-64 POS/RPR VSR Optics SPA uses fixed optical transceivers, one for receive
(RX) and one for transmit (TX), for SONET and SDH connection to the network. Only Very Short Reach
(VSR) optics are supported.
The 1-Port OC-192c/STM-64 POS/RPR VSR Optics SPA uses multimode MTP-type connectors:
•
Use a multimode optical fiber cable to connect your router to a network.
Figure 3-19
OC-192c/STM-64 POS/RPR VSR Optics SPA.
Figure 3-19
1
1

5-Port Gigabit Ethernet SPA Overview

The following sections describe the 5-Port Gigabit Ethernet SPA:
•
•
Cisco CRS-1 Carrier Routing System SIP and SPA Hardware Installation Guide
3-28
Multimode—9.95 Gbps, OC-192 optical fiber (SONET STS-192c or SDH STM-64c)
Use a multimode optical fiber that has a modal-field diameter of 8.7 ±0.5 microns. (Nominal
diameter is approximately 10/125 microns.)
shows the cable type for use with the fixed optical transceiver module on the 1-Port
Simplex MTP Cable Connector (Multimode—VSR Only)
2
MTP female connector
5-Port Gigabit Ethernet SPA LEDs, page 3-29
5-Port Gigabit Ethernet SPA Cables and Connectors, page 3-29
Chapter 3 Overview: Cisco CRS-1 Shared Port Adapters
2 Spring-action disconnect latch
OL-17439-01
