Chapter 3 Overview: Cisco CRS-1 Shared Port Adapters

1-Port OC-192c/STM-64 POS/RPR XFP SPA LEDs

The 1-Port OC-192c/STM-64 POS/RPR XFP SPA has six LEDs, as shown in
Figure 3-16
1
2
3
Table 3-12
Table 3-12
LED Label
WRAP
PASSTHRU
MATESYNC
CARRIER
ACTIVE
STATUS
OL-17439-01
1-Port OC-192c/STM-64 POS/RPR XFP SPA Faceplate
1 3
2
WRAP LED
PASSTHRU LED
MATESYNC LED
describes the 1-Port OC-192c/STM-64 POS/RPR XFP SPA LEDs.
1-Port OC-192c/STM-64 POS/RPR XFP SPA LEDs
Color State
Off Off
Green On
Amber On
Off Off
Amber On
Off Off
Green On
Off Off
Green On
Amber On
Blinking SRP mode mismatch alarm is indicated.
Off Off
Green On
Amber On
Off Off
Green On
Amber On
Cisco CRS-1 Carrier Routing System SIP and SPA Hardware Installation Guide
1-Port OC-192c/STM-64 POS/RPR XFP SPA Overview
4
5
4 CARRIER LED
5 ACTIVE LED
6 STATUS LED
Meaning
Port is not in wrap mode.
Port is in wrap mode somewhere on the ring.
Port is in wrap mode locally.
Port is not in pass-through mode.
Port is in pass-through mode.
Mate port is not synchronized.
Mate port is synchronized.
Port is not enabled by software.
Port is enabled by software, and there is a valid SONET signal
without alarms.
Port is enabled by software, and there is at least one alarm (LOS,
LOF, RDI, and so on).
Port is not enabled by software.
Port is enabled by software, and loopback is off.
Port is enabled by software, and loopback is on.
SPA power off.
SPA is ready and operational.
SPA power is on and good, and the SPA is being configured.
Figure 3-16.
SPA-0C192POS-XFP
6
3-23
