Appendix B: TPP0101 and TPP0201 Series 10X Passive Probes Information

Optional Accessories

Specifications
118
You can order the following accessories for your probe.
Accessory
Alligator Ground Lead, 12 in
6" Clip-on Ground Lead
Ground Spring, Short, 2 ea.
MicroCKT Test Tip
Micro Hook Tip
Universal IC Cap
Circuit Board Test Point/PCB Adapter
Wire, spool, 32 AWG
Table 7: Electrical and mechanical specifications
Characteristic
Bandwidth (–3 dB)
System attenuation accuracy
Compensation range
System input resistance
@ DC
System input capacitance
System rise time (typical)
Propagation delay
Maximum input voltage
Cable length
Table 8: Environmental specifications
Characteristics
Temperature
Operating
Nonoperating
Humidity
Operating and
Non-Operating
Altitude
Operating
Nonoperating
TDS2000C and TDS1000C-EDU Series Oscilloscope User Manual
TPP0101
DC to 100 MHz
10:1 ±3.2%
TPP0101:
15 pF – 25 pF
10 MΩ ±1.5%
<12 pF
<3.5 ns
~6.1 ns
300 V CAT II
RMS
1.3 m
Description
–10 °C to +55 °C (14 °F to +131 °F)
–51 °C to +71 °C (–60 °F to +160 °F)
5% to 95% relative humidity (%RH) up to +30 °C (86 °F), 5% to
65% RH above +30° C up to +55 °C (131 °F)
3.0 km (10,000 ft) maximum
12.2 km (40,000 ft) maximum
Part number
196-3512-xx
196-3198-xx
016-2034-xx
206-0569-xx
013-0363-xx
013-0366-xx
016-2016-xx
020-3045-xx
TPP0201
DC to 200 MHz
10:1 ±3.2%
TPP0201:
15 pF – 25 pF
10 MΩ ±1.5%
<12 pF
<2.3 ns
~6.1 ns
300 V CAT II
RMS
1.3 m
