Reference
Save Waveform
Recall Setup
94
The Save Waveform action saves the specified waveform to a file named
TEKnnnn.CSV, or to reference memory. The oscilloscope saves waveform data to
files as "comma separated values" (.CSV format), which are ASCII text strings
that list the time (relative to the trigger) and amplitude values for each of the
2500 waveform data points. You can import .CSV files into many spreadsheet
and math analysis applications.
Options Settings or submenus
Save To File
Ref
Source 1 CH(x), Ref(x), MATH
To
Ref(x)
Select Folder
Change Folder
New Folder
Save filename (such as
TEK0000.CSV)
1 Waveform must be displayed to save it as a reference waveform.
The Recall Setup action recalls an oscilloscope setup file from a USB flash drive
or from a location in nonvolatile setup memory.
Options Settings or submenus
Recall From Setup
File
Setup 1 to 10
Select File
Change Folder
Recall
filename (such as
TEK0000.SET)
TDS2000C and TDS1000C-EDU Series Oscilloscope User Manual
Comments
Specifies to save the source waveform
data to a file on a USB flash drive
Specifies to save the source waveform
data in reference memory
Specifies which source waveform to
save
Specifies the reference memory location
in which to save the source waveform
Lists the contents of the current USB
flash drive folder
(See page 64, File Management
Conventions.) (See page 103, File
Utilities for the USB Flash Drive.)
Saves the waveform data to the
automatically generated file name in the
current USB flash drive folder
Comments
Specifies to recall a setup from the
nonvolatile memory
Specifies to recall a setup file from a
USB flash drive
Specifies which setup location in
nonvolatile setup memory to recall
Lists the contents of the current USB
flash drive folder to select a file from
(See page 64, File Management
Conventions.) (See page 103, File
Utilities for the USB Flash Drive.)
Recalls the settings from the specified
nonvolatile memory location
Recalls the oscilloscope settings from
the specified USB flash drive file
