TDS2000C and TDS1000C-EDU Series Oscilloscope User Manual
Active menu or option
Vertical ► Probe ►
Voltage ► Attenuation
Vertical ► Probe ►
Current ► Scale
AutoRange. Displays the Autorange Menu, and activates or deactivates the
autoranging function. When autoranging is active, the adjacent LED lights.
Save/Recall. Displays the Save/Recall Menu for setups and waveforms.
Measure. Displays the automated measurements menu.
Acquire. Displays the Acquire Menu.
Ref. Displays the Reference Menu to quickly display and hide reference
waveforms stored in the oscilloscope non-volatile memory.
Utility. Displays the Utility Menu.
Cursor. Displays the Cursor Menu. Cursors remain visible (unless the Type
option is set to Off) after you leave the Cursor Menu but are not adjustable.
Display. Displays the Display Menu.
Help. Displays the Help Menu.
Default Setup. Recalls the factory setup.
AutoSet. Automatically sets the oscilloscope controls to produce a usable display
of the input signals.
Single. (Single sequence) Acquires a single waveform and then stops.
Run/Stop. Continuously acquires waveforms or stops the acquisition.
Starts the print operation to a PictBridge compatible printer, or performs the
Save function to the USB flash drive.
Save. An LED indicates when the print button is configured to save data to the
USB flash drive.
Knob function Description
Value entry For a channel menu (such as the CH
1 menu), sets the attenuation factor in
the oscilloscope
Value entry For a of channel menu (such as the
CH 1 menu), sets the scale in the
oscilloscope
Operating Basics
17
