The Autorange function is usually more useful than Autoset in the following
situations:
Analyzing a dynamically changing signal
Quickly comparing a sequence of several signals without adjusting the
oscilloscope. This is very useful if you need to use two probes at the same
time, or if you need to use a probe in one hand and are holding something
else in the other.
Controlling which settings the oscilloscope automatically adjusts
If your signals vary in frequency, but have similar amplitudes, you can use
Horizontal Only autoranging. The oscilloscope will adjust the horizontal settings,
but leave the vertical settings unchanged. This way, you can visually estimate
the amplitude of the signal without worrying about the vertical scale changing.
Vertical Only autoranging works similarly, adjusting vertical parameters and
leaving the horizontal settings unchanged.
When you push the AutoSet button, the oscilloscope identifies the type of
waveform and adjusts controls to produce a usable display of the input signal.
Function
Acquire mode
Cursors
Display format
Display type
Horizontal position
Horizontal scale
(seconds/division)
Trigger coupling
Trigger holdoff
Trigger level
Trigger mode
Trigger source
Trigger slope
Trigger type
Trigger Video Polarity
Setting
Adjusted to Sample or Peak Detect
Off
Set to YT
Set to Dots for a video signal, set to Vectors for an FFT
spectrum; otherwise, unchanged
Adjusted
Adjusted
Adjusted to DC, Noise Reject, or HF Reject
Minimum
Set to 50%
Auto
Adjusted; refer to the information after this table; cannot
use Autoset on the Ext Trig signal
Adjusted
Edge or Video
Normal
Reference
