Getting Started

General Features

TDS2000C and TDS1000C-EDU Series Oscilloscope User Manual
TDS2000C and TDS1000C-EDU Series Digital Storage Oscilloscopes are small,
lightweight, benchtop instruments, which you can use to take ground-referenced
measurements.
This chapter describes how to do the following tasks:
Install your product
Perform a brief functional check
Perform a probe check and compensate probes
Match your probe attenuation factor
Use the self calibration routine
NOTE.
You can select a language to display on the screen when you power on the
oscilloscope. At any time, you can also access the Utility ► Language option to
select a language.
The next table and list describe the general features.
Model Channels
TDS1001C-EDU 2
TDS1002C-EDU 2
TDS1012C-EDU 2
2
TDS2001C
TDS2002C 2
TDS2004C 4
TDS2012C 2
TDS2014C 4
2
TDS2022C
4
TDS2024C
Context-sensitive help system
Color LCD display
Selectable 20 MHz bandwidth limit
2500 point record length for each channel
Autoset
Autoranging
Bandwidth Sample rate
40 MHz 500 MS/s
60 MHz 1 GS/s
100 MHz 1 GS/s
50 MHz
500 MS/s
70 MHz 1.0 GS/s
70 MHz 1.0 GS/s
100 MHz 2.0 GS/s
100 MHz 2.0 GS/s
200 MHz
2.0 GS/s
200 MHz
2.0 GS/s
Display
Color
Color
Color
Color
Color
Color
Color
Color
Color
Color
1
