Appendix E: Default Setup

TDS2000C and TDS1000C-EDU Series Oscilloscope User Manual
This appendix describes the options, buttons and controls that change settings
when you push the Default Setup button. The last page of this appendix lists
settings that do not change.
NOTE. When you push the Default Setup button, the oscilloscope displays the
CH1 waveform and removes all other waveforms.
Menu or system
ACQUIRE
AUTORANGE
CURSOR
DISPLAY
HORIZONTAL
MATH
MEASURE (all)
TRIGGER (common)
Option, button, or knob
(three mode options)
Averages
Run/Stop
Autorange
Mode
Type
Source
Horizontal (amplitude)
Vertical (time)
Type
Persist
Format
Window
Trig Knob
Position
Scale (seconds/division)
Window Zone
Operation
Sources
Position
Vertical Scale
FFT operation:
Source
Window
FFT Zoom
Source
Type
Type
Source
Default setting
Sample
16
RUN
Off
Vertical and Horizontal
Off
CH1
+/- 3.2 divs
+/- 4 divs
Vectors
Off
YT
Main
Level
0.00 s
500 ms
50 ms
-
CH1 - CH2
0 divs
2 V
CH1
Hanning
X1
CH1
None
Edge
CH1
127
