Save Setup
TDS2000C and TDS1000C-EDU Series Oscilloscope User Manual
Options Settings or submenus
Select Folder
Change Folder
New Folder
Layout
Landscape
Ink Saver
filename (such as
Save
TEK0000.TIF)
1
(See page 90, Print.)
When the print button option is set to Saves Image to File, the oscilloscope saves
screen images to a USB flash drive when you push the Save button. (See page 68,
Saves Image to File.)
The Save Setup action saves the current oscilloscope settings to a file named
TEKnnnn.SET in a specified folder, or in nonvolatile setup memory. A setup file
contains an ASCII text string that lists the oscilloscope settings.
Options Settings or submenus
Save To Setup
File
Setup 1 to 10
Select Folder
Change Folder
New Folder
Save filename (such as
TEK0000.SET)
When the print button option is set to Saves All to Files, the oscilloscope saves
oscilloscope setup files to a USB flash drive when you push the Save button. (See
page 67, Saves All to Files.)
Comments
Lists the contents of the current USB
flash drive folder and displays the folder
options
(See page 64, File Management
Conventions.) (See page 103, File
Utilities for the USB Flash Drive.)
1 , Portrait, Select portrait or landscape image
layout
1 , On, Off Activates or deactivates Ink Saver mode
Saves the screen image to the
automatically generated file name in the
current USB flash drive folder
Comments
Saves the current oscilloscope settings
to a location in the nonvolatile setup
memory
Saves the current oscilloscope settings
to a file on the USB flash drive
Specifies which nonvolatile setup
memory location to save to
Lists the contents of the current USB
flash drive folder
(See page 64, File Management
Conventions.) (See page 103, File
Utilities for the USB Flash Drive.)
Saves the settings to the automatically
generated file name in the current USB
flash drive folder
Reference
93
