Print - Tektronix TDS2000C series User Manual

Reference

Print

Option
Ink Saver
Layout 1
Abort Printing
Paper Size 2
Image Size 2
Paper Type 2
Print Quality 2
Date Print 2
ID Print 2
1
The printer may override your selection for best fit.
2
If your selection is not supported by the printer, the oscilloscope uses the Default setting.
90
When the Save All ► PRINT Button option is set to Prints, you can push the
print button to send the screen image to a printer.
You can set up the oscilloscope to send a screen image to your printer through the
Utility ► Options ► Printer Setup menu.
Setting
On, Off
Portrait, Landscape
Default, L, 2L, Hagaki Postcard, Card Size, 10 x 15 cm, 4" x 6", 8"
x 10", Letter, 11" x 17", A0, A1, A2, A3, A4, A5, A6, A7, A8, A9,
B0, B1, B2, B3, B4, B5, B6, B7, B8, B9, 89 mm Roll (L), 127 mm
Roll (2L), 100 mm Roll (4"), 210 mm Roll (A4)
Default, 2.5 x 3.25 in, L (3.5 x 5 in), 4 x 6 in, 2L (5 x 7 in), 8 x 10 in,
4L (7 x 10 in), E, Card, Hagaki card, 6 x 8 cm, 7 x 10 cm, 9 x
13 cm, 10 x 15 cm, 13 x 18 cm, 15 x 21 cm, 18 x 24 cm, A4, Letter
Default, Plain, Photo, Fast Photo
Default, Normal, Draft, Fine
Default, Off, On
Default, Off, On
The alternative function of the print button is to save data to a USB flash drive.
(See page 63, USB Flash Drive and Device Ports.)
The oscilloscope was designed to print to any PictBridge compatible printer.
Refer to the product documentation for your printer to determine if the printer is
PictBridge compatible.
TDS2000C and TDS1000C-EDU Series Oscilloscope User Manual
Comments
Prints the screen image on a
white background when you
select On
Printer output orientation
Stops sending the screen image
to the printer
Displays settings available on
your PictBridge compatible
printer
