Fibre Alliance MIB Objects

Statistics Group

Note:
Port types are aggregated into a port type class, such as all the fabric port types.
There is one and only one statistics table for each individual port. For all objects in the
statistics table, if the object is not supported by the conn unit, then the high order bit is
set to 1 with all other bits set to zero (for example, the last eight bytes of the returned
value might be ...:80 00 00 00 00 00 00 00).
The high order bit is reserved to indicate whether the object is supported. All objects
start at a value of zero at hardware initialization and continue incrementing until end of
63 bits and then wrap to zero.
This is the case for all Class 1 Frames, and HP does not support them.

connUnitPortStatTable

OID
Description

connUnitPortStatEntry

OID
Description
Index

connUnitPortStatUnitId

OID
Description

connUnitPortStatIndex

OID
Description
330
Not supported in Fabric OS v2.6.1.
1.3.6.1.3.94.4.5
A list of statistics for the fabric port types.
1.3.6.1.3.94.4.5.1
An entry describing port statistics.
connUnitPortStatUnitId
connUnitPortStatIndex
1.3.6.1.3.94.4.5.1.1
The connUnitId of the connectivity unit that contains this port
stat table.
1.3.6.1.3.94.4.5.1.2
A unique value among all entries in this table, between 0 and
connUnitNumPort[connUnitPortUnitId].
MIB Version 3.1.x/4.1.x Reference Guide
