Fibre Alliance MIB Objects

connUnitPortState

OID
Description
Note:
(disabled, testing, faulted).

connUnitPortStatus

OID
Description
Note:
if not faulty with GBIC, 3 (warning) if not faulty but no GBIC, or 5 (failure) if faulty.
308
1.3.6.1.3.94.1.10.1.6
The state of the port hardware. Possible values are:
unavailable (1): Do not use.
online (2):
offline (3):
bypassed (4):
diagnostics (5):
For an E, F, or FL_port, the value is online. For a U_port, the value is offline
1.3.6.1.3.94.1.10.1.7
An overall protocol status for the port. Possible values are:
unknown (1)
unused (2):
ready (3):
warning (4):
failure (5):
notparticipating (6):Loop not participating and does not
initializing (7):
bypass (8):
ols (9):
For an E, F, or FL_port, the value is 3 (ok). For a U_port, the value is 2 (unused)
Available for meaningful work.
Not available for meaningful work.
No longer used.
Map to your testing. (Not supported in
Fabric OS v2.6.1.)
Device cannot report this status.
FCAL Loop or FCPH Link reset
protocol initialization has completed.
Do not use.
Do not use.
have a loop address.
Protocol is proceeding.
Do not use.
FCP offline status. (Not supported in
Fabric OS v2.6.1).
MIB Version 3.1.x/4.1.x Reference Guide
