FE MIB Objects

fcFxPortBbCreditModel

OID
Description

Error Group

This group consists of tables that contain information about the various types of
errors detected. The management station may use the information in this group to
determine the quality of the link between the FxPort and its attached NxPort.
Implementation of this group is optional.
FxPort Error Table
This table contains, one entry for each FxPort in the Fabric Element and counters
recording numbers of errors detected since the management agent re-initialized.
Note:
Link ErrorStatus Block.

fcFxPortErrorTable

OID
Description

fcFxPortErrorEntry

OID
Description
Index
118
1.3.6.1.2.1.75.1.2.3.1.12
Identifies the BB_Credit model used by the FxPort. The regular
model refers to the buffer-to-buffer flow control mechanism
defined in FC-PH [1] is used between the F_Port and the
N_Port. For FL_Ports, the Alternate Buffer-to-Buffer flow
control mechanism as defined in FC-AL [4] is used between the
FL_Port and any attached NL_Ports.
The first 6 columnar objects after the port index correspond to the counters in the
1.3.6.1.2.1.75.1.3.1
A table that contains, one entry for each FxPort, counters that
record the numbers of errors detected.
1.3.6.1.2.1.75.1.3.1.1
An entry containing error counters of a FxPort.
fcFxPortErrorModuleIndex, fcFxPortErrorFxPortIndex
MIB Version 3.1.x/4.1.x Reference Guide
