Entity MIB Objects

Overview

The entityMIB is the MIB module for representing multiple logical entities
supported by a single SNMP agent. This MIB is supported only in Fabric OS v4.x
and is not supported in Fabric OS v3.x or Fabric OS v2.6.1.
The descriptions of each of the MIB variables in this chapter come directly from
the entityMIB itself. The notes that follow the descriptions typically pertain to
HP-specific information and are provided by HP.
The object types in entityMIB are organized into the following groupings:

Entity MIB System Organization of MIB Objects

Figure 13
entityMIB file system.
- iso (1)
- org (3)
- dod (6)
Figure 13: Overall Tree Structure for entityMIB
164
Entity MIB Objects
Entity MIB Traps
Entity Conformance Groups
through Figure 14
- internet (1)
- mgmt (2)
- mib-2 (1)
- entityMIB (47)
- entityMIBObjects (1)
- entityPhysical (1)
- entityLogical (2)
- entityMapping (3)
- entityGeneral (4)
- entityMIBTraps (2)
- entityMIBTrapPrefix (0)
depict the organization and structure of the
MIB Version 3.1.x/4.1.x Reference Guide
