Fibre Alliance MIB Objects
connUnitPortType
OID
Description
Note:
306
1.3.6.1.3.94.1.10.1.3
The port type. Possible values are:
unknown (1)
other (2)
not-present (3)
hub-port (4)
n-port (5):
l-port (6):
fl-port (7):
f-port (8):
e-port (9):
g-port (10):
domain-ctl (11):
hub-controller (12)
scsi (13):
escon (14)
lan (15)
wan (16)
ac (17):
dc (18):
ssa (19):
Mapped as:
U_port = 10 (g-port)
F_port = 8 (f-port)
FL_port = 7 (fl-port)
E_port = 9 (e-port)
End port for fabric.
End port for loop.
Public loop.
Fabric port.
Fabric expansion port.
Generic fabric port.
Domain controller.
Parallel SCSI port.
AC power line. (Not supported in
Fabric OS v2.6.1.)
DC power line. (Not supported in
Fabric OS v2.6.1)
Serial storage architecture. (Not
supported in Fabric OS v2.6.1.)
MIB Version 3.1.x/4.1.x Reference Guide
