fcFxPortPhysOperStatus

OID
Description

fcFxPortPhysLastChange

OID
Description

fcFxPortPhysRttov

OID
Description

FxPort Fabric Login Table

This table contains one entry for each FxPort in the Fabric Element, and the
Service Parameters that have been established from the most recent Fabric Login,
whether implicit or explicit.
MIB Version 3.1.x/4.1.x Reference Guide
1.3.6.1.3.42.2.1.2.3.1.4
The current operational status of the FxPort. Possible values are:
online (1):
offline (2):
testing (3):
link-failure (4): Failure after online/testing.
The testing (3) indicates that no operational frames can be
passed. If fcFxPortPhysAdminStatus is offline (2) then
fcFxPortPhysOperStatus should be offline (2). If
fcFxPortPhysAdminStatus is changed to online (1), then
fcFxPortPhysOperStatus should change to 1 (online) if the
FxPort is ready to accept Fabric Login request from the attached
NxPort; it should proceed and remain in the link-failure (4) state
if and only if there is a fault that prevents it from going to the
online (1) state.
1.3.6.1.3.42.2.1.2.3.1.5
The value of sysUpTime at the time the FxPort entered its
current operational status. A value of zero indicates that the
FxPort's operational status has not changed since the agent last
restarted.
1.3.6.1.3.42.2.1.2.3.1.6
The Receiver_Transmitter_Timeout value of the FxPort. This is
used by the receiver logic to detect Loss of Synchronization.
Login may proceed.
Login cannot proceed.
Port is under test.
FE MIB Objects
151
