NOTE:
If the HP D2D is connected to a Fibre Channel network, it is not possible to create a default library
for the host automatically during installation. You must use this page to create and configure devices
that can be accessed by the host.
The top half of the page shows the a list of devices available on the HP D2D Backup System. Summary
information is provided for each device, as follows:
Table 6 Device parameters (top half of the page)
Name
Cartridges
Role
Connection
Device Type
This is the name that is used to identify that device (library or autoloader).
You may like to enter a name that identifies the host or backup job with
which it is associated.
This is the number of cartridges available on the device, which is determined
by the Emulation Type selected when the device was created.
This is the role of the library, which may be non-replicating, replication source
or replication target.
If a device is shown as not connected, this indicates that the iSCSI Initiator
on the host has not logged on. For more information, see
tab" on page 61.
With a FC device, this field shows the connection status of the FC link and
its speed (down, 1G, 2G, 4G).
This is the emulation type used by the backup software. It is selected during
installation or when you create a device.
D2D Backup System HP D2D4112
"Targets
