Enterasys S-Series Upgrade Installation Manual
Poe subsystem
Hide thumbs
Also See for S-Series:
- Hardware installation manual (96 pages) ,
- Hardware installation manual (58 pages) ,
- Hardware installation manual (40 pages)
Subscribe to Our Youtube Channel
Related Manuals for Enterasys S-Series
Summary of Contents for Enterasys S-Series
- Page 1 Enterasys S-Series ® PoE Subsystem Upgrade Installation Guide S8-POE-8BAY-UGK S8-POE-4BAY-UGK S4-POE-4BAY-UGK S3-POE-4BAY-UGK P/N 9034457-03...
- Page 3 Elektrischer Gefahrenhinweis: Installationen sollten nur durch ausgebildetes und qualifiziertes Personal vorgenommen werden. Notice Enterasys Networks reserves the right to make changes in specifications and other information contained in this document and its web site without prior notice. The reader should in all cases consult Enterasys Networks to determine whether any such changes have been made. The hardware, firmware, or software described in this document is subject to change without notice. IN NO EVENT SHALL ENTERASYS NETWORKS BE LIABLE FOR ANY INCIDENTAL, INDIRECT, SPECIAL, OR CONSEQUENTIAL DAMAGES WHATSOEVER (INCLUDING BUT NOT LIMITED TO LOST PROFITS) ARISING OUT OF OR RELATED TO THIS DOCUMENT, WEB SITE, OR THE INFORMATION CONTAINED IN THEM, EVEN IF ENTERASYS NETWORKS HAS BEEN ADVISED OF, KNEW OF, OR SHOULD HAVE KNOWN OF, THE POSSIBILITY OF SUCH DAMAGES. Enterasys Networks, Inc. 50 Minuteman Road Andover, MA 01810 © 2010 Enterasys Networks, Inc. All rights reserved. Part Number: 9034457‐03 June 2010 ENTERASYS, ENTERASYS NETWORKS, ENTERASYS SECURE NETWORKS, and any logos associated therewith, are trademarks or registered trademarks of Enterasys Networks, Inc., in the United States and/or other countries. For a complete list of Enterasys trademarks, see http://www.enterasys.com/company/trademarks.aspx. All other product names mentioned in this manual may be trademarks or registered trademarks of their respective companies. Documentation URL: http://www.enterasys.com/support/manuals Documentacion URL: http://www.enterasys.com/support/manuals Dokumentation im Internet: http://www.enterasys.com/support/manuals...
- Page 4 Regulatory Compliance Information Federal Communications Commission (FCC) Notice This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a class A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment uses, generates, and can radiate radio frequency energy and if not installed in accordance with the operator’s manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause interference in which case the user will be required to correct the interference at his own expense. WARNING: Changes or modifications made to this device which are not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Industry Canada Notice This digital apparatus does not exceed the class A limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications. Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques de la class A prescrites dans le Règlement sur le brouillage radioélectrique édicté par le ministère des Communications du Canada. Class A ITE Notice WARNING: This is a Class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. Clase A. Aviso de ITE ADVERTENCIA: Este es un producto de Clase A. En un ambiente doméstico este producto puede causar interferencia de radio ...
- Page 5 In accordance with Directive 2002/96/EC of the European Parliament on waste electrical and electronic equipment (WEEE): The symbol above indicates that separate collection of electrical and electronic equipment is required and that this product was placed on the European market after August 13, 2005, the date of enforcement for Directive 2002/96/EC. When this product has reached the end of its serviceable life, it cannot be disposed of as unsorted municipal waste. It must be collected and treated separately. It has been determined by the European Parliament that there are potential negative effects on the environment and human health as a result of the presence of hazardous substances in electrical and electronic equipment. It is the users’ responsibility to utilize the available collection system to ensure WEEE is properly treated. For information about the available collection system, please go to www.enterasys.com/services/support/ or contact Enterasys Customer Support at 353 61 705586 (Ireland). Battery Notice This product contains a battery used to maintain product information. If the battery should need replacement it must be replaced by Service Personnel. Please contact Technical Support for assistance. Caution: There is an explosion risk if you replace the battery with the incorrect type. Dispose of expended battery in accordance with local disposal regulations.
- Page 6 SJ/T 11363-2006 standard. This table shows where these substances may be found in the supply chain of Enterasys’ electronic information products, as of the date of sale of the enclosed product. Note that some of the component types listed above may or may not be a part of the enclosed product.
- Page 7 Safety Information Class 1 Laser Transceivers The single mode interface modules use Class 1 laser transceivers. Read the following safety information before installing or operating these modules. The Class 1 laser transceivers use an optical feedback loop to maintain Class 1 operation limits. This control loop eliminates the need for maintenance checks or adjustments. The output is factory set, and does not allow any user adjustment. Class 1 Laser transceivers comply with the following safety standards: • 21 CFR 1040.10 and 1040.11 U.S. Department of Health and Human Services (FDA). • IEC Publication 825 (International Electrotechnical Commission). • CENELEC EN 60825 (European Committee for Electrotechnical Standardization). When operating within their performance limitations, laser transceiver output meets the Class 1 accessible emission limit of all three standards. Class 1 levels of laser radiation are not considered hazardous. When the connector is in place, all laser radiation remains within the fiber. The maximum amount of radiant power exiting the ‐6 fiber (under normal conditions) is ‐12.6 dBm or 55 x 10 watts.
- Page 8 Declaration of Conformity Application of Council Directive(s): 2004/108/EC 2006/95/EC Manufacturer’s Name: Enterasys Networks, Inc. Manufacturer’s Address: 50 Minuteman Road Andover, MA 01810 European Representative Name: Enterasys Networks, Ltd. European Representative Address: Nexus House, Newbury Business Park London Road, Newbury Berkshire RG14 2PZ, England Conformance to Directive(s)/Product Standards: EC Directive 2004/108/EC EN 55022:2006 EN 55024:1998 EN 61000‐3‐2:2006 EN 61000‐3‐3:1995 EC Directive 2006/95/EC EN 60950‐1:2006 EN 60825‐1:2007 EN 60825‐2:2004 Equipment Type/Environment: Information Technology Equipment, for use in a Commercial or Light Industrial Environment. Enterasys Networks, Inc. declares that the equipment packaged with this notice conforms to the above directives.
- Page 9 Enterasys Networks, Inc. Firmware License Agreement BEFORE OPENING OR UTILIZING THE ENCLOSED PRODUCT, CAREFULLY READ THIS LICENSE AGREEMENT. This document is an agreement (“Agreement”) between the end user (“You”) and Enterasys Networks, Inc., on behalf of itself and its Affiliates (as hereinafter defined) (“Enterasys”) that sets forth Your rights and obligations with respect to the Enterasys software program/firmware (including any accompanying documentation, hardware or media) (“Program”) in the package and prevails over any additional, conflicting or inconsistent terms and conditions appearing on any purchase order or other document submitted by You. “Affiliate” means any person, partnership, corporation, limited liability company, other form of enterprise that directly or indirectly through one or more intermediaries, controls, or is controlled by, or is under common control with the party specified. This Agreement constitutes the entire understanding between the parties, with respect to the subject matter of this Agreement. The Program may be contained in firmware, chips or other media. BY INSTALLING OR OTHERWISE USING THE PROGRAM, YOU REPRESENT THAT YOU ARE AUTHORIZED TO ACCEPT THESE TERMS ON BEHALF OF THE END USER (IF THE END USER IS AN ENTITY ON WHOSE BEHALF YOU ARE AUTHORIZED TO ACT, “YOU” AND “YOUR” SHALL BE DEEMED TO REFER TO SUCH ENTITY) AND THAT YOU AGREE THAT YOU ARE BOUND BY THE TERMS OF THIS AGREEMENT, WHICH INCLUDES, AMONG OTHER PROVISIONS, THE LICENSE, THE DISCLAIMER OF WARRANTY AND THE LIMITATION OF LIABILITY. IF YOU DO NOT AGREE TO THE TERMS OF THIS AGREEMENT OR ARE NOT AUTHORIZED TO ENTER INTO THIS AGREEMENT, ENTERASYS IS UNWILLING TO LICENSE THE PROGRAM TO YOU AND YOU AGREE TO RETURN THE UNOPENED PRODUCT TO ENTERASYS OR YOUR DEALER, IF ANY, WITHIN TEN (10) DAYS FOLLOWING THE DATE OF RECEIPT FOR A FULL REFUND. IF YOU HAVE ANY QUESTIONS ABOUT THIS AGREEMENT, CONTACT ENTERASYS NETWORKS, LEGAL DEPARTMENT AT (978) 684‐1000. You and Enterasys agree as follows: LICENSE. You have the non‐exclusive and non‐transferable right to use only the one (1) copy of the Program provided in ...
- Page 10 CONTRACT, TORT OR OTHERWISE, SHALL NOT EXCEED THE TOTAL AMOUNT OF FEES PAID TO ENTERASYS BY YOU FOR THE RIGHTS GRANTED HEREIN. AUDIT RIGHTS. You hereby acknowledge that the intellectual property rights associated with the Program are of critical value to Enterasys, and, accordingly, You hereby agree to maintain complete books, records and accounts showing (i) license fees due and paid, and (ii) the use, copying and deployment of the Program. You also grant to Enterasys and its authorized representatives, upon reasonable notice, the right to audit and examine during Your normal business hours, Your books, records, accounts and hardware devices upon which the Program may be deployed to verify compliance with this Agreement, including the verification of the license fees due and paid Enterasys and the use, copying and deployment of the Program. Enterasys’ right of examination shall be exercised reasonably, in good faith and in a manner calculated to not unreasonably interfere with Your business. In the event such audit discovers non‐compliance with this Agreement, including copies of the Program made, used or deployed in breach of this Agreement, You shall promptly pay to Enterasys the appropriate license fees. Enterasys reserves the right, to be exercised in its sole discretion and without prior notice, to terminate this license, effective immediately, for failure to comply with this Agreement. Upon any such termination, You shall immediately cease all use of the Program and shall return to Enterasys the Program and all copies of the Program. OWNERSHIP. This is a license agreement and not an agreement for sale. You acknowledge and agree that the Program constitutes trade secrets and/or copyrighted material of Enterasys and/or its suppliers. You agree to implement reasonable security measures to protect such trade secrets and copyrighted material. All right, title and interest in and to the Program shall remain with Enterasys and/or its suppliers. All rights not specifically granted to You shall be reserved to Enterasys. 10. ENFORCEMENT. You acknowledge and agree that any breach of Sections 2, 4, or 9 of this Agreement by You may cause Enterasys irreparable damage for which recovery of money damages would be inadequate, and that Enterasys may be entitled to seek timely injunctive relief to protect Enterasys’ rights under this Agreement in addition to any and all remedies available at law. 11. ASSIGNMENT. You may not assign, transfer or sublicense this Agreement or any of Your rights or obligations under this Agreement, except that You may assign this Agreement to any person or entity which acquires substantially all of Your stock assets. Enterasys may assign this Agreement in its sole discretion. This Agreement shall be binding upon and inure to the benefit of the parties, their legal representatives, permitted transferees, successors and assigns as permitted by this Agreement. Any attempted assignment, transfer or sublicense in violation of the terms of this Agreement shall be void and a breach of this Agreement. 12. WAIVER. A waiver by Enterasys of a breach of any of the terms and conditions of this Agreement must be in writing and will not be construed as a waiver of any subsequent breach of such term or condition. Enterasys’ failure to enforce a term upon Your breach of such term shall not be construed as a waiver of Your breach or prevent enforcement on any other occasion. viii...
- Page 11 13. SEVERABILITY. In the event any provision of this Agreement is found to be invalid, illegal or unenforceable, the validity, legality and enforceability of any of the remaining provisions shall not in any way be affected or impaired thereby, and that provision shall be reformed, construed and enforced to the maximum extent permissible. Any such invalidity, illegality, or unenforceability in any jurisdiction shall not invalidate or render illegal or unenforceable such provision in any other jurisdiction. 14. TERMINATION. Enterasys may terminate this Agreement immediately upon Your breach of any of the terms and conditions of this Agreement. Upon any such termination, You shall immediately cease all use of the Program and shall return to Enterasys the Program and all copies of the Program.
-
Page 13: Table Of Contents
Placing the PoE Subsystem on the S-Series Chassis (S3 Chassis/S-POE-4BAY-PWR Example) ... 2-6 Securing the PoE Subsystem to the S-Series Chassis (S3 Chassis/S-POE-4BAY-PWR Example).. 2-7 Removing the Rear Panels from the S-Series Chassis and the PoE Subsystem (S3 Chassis/S-POE- 4BAY-PWR Example)......................... 2-8 Location of Rear Panel Screws on the S-POE-8BAY-PWR PoE Subsystem ........ - Page 14 Inserting the S-POE-PS Power Supply in the PoE Subsystem ............3-2 Removing a Cover Plate from the PoE Subsystem ................3-3 Tables S-Series PoE Upgrade Kits ........................ 1-1 Hardware Contents of PoE Upgrade Kit..................... 2-2 Number of Screws to Remove......................2-8 Contents of S-POE-PS Power Supply Carton ..................
-
Page 15: About This Guide
Installing the PoE Upgrade Kit Installing PoE power supplies. Chapter 3, Installing the PoE Power Supplies Specifications, environmental requirements, and physical Appendix A, Specifications and properties of the PoE subsystems. Regulatory Compliance Enterasys S-Series PoE Subsystem Upgrade Installation Guide xiii... -
Page 16: Related Documents
Related Documents Related Documents S‐Series manuals can be obtained from the World Wide Web in Adobe Acrobat Portable Document Format (PDF) at the following site: http://www.enterasys.com/support/manuals Typographical Conventions The following typographical conventions and icons are used in this document. blue type Indicates a hypertext link. When reading this document online, click the text in blue to go to the referenced figure, table, or section. Note: Calls the reader’s attention to any item of information that may be of special importance. -
Page 17: Getting Help
Internet mail support@enterasys.com To expedite your message, please type [S-Series] in the subject line. To send comments or suggestions concerning this document to the Technical Publications Department: techpubs@enterasys.com To expedite your message, include the document part number in the Email message. - Page 18 Getting Help xvi About This Guide...
-
Page 19: Chapter 1: Introduction
S-POE-4BAY-PWR S4-POE-4BAY-UGK S-POE-4BAY-PWR S8-POE-4BAY-UGK S-POE-4BAY-PWR S8-POE-8BAY-UGK S-POE-8BAY-PWR Depending on the S‐Series chassis that you want to upgrade to PoE, your PoE upgrade kit will include one of the following PoE subsystem models, which you must install on top of the S‐Series chassis: • S‐POE‐4BAY‐PWR — A four‐bay PoE subsystem for up to four S‐POE‐PS power supplies, which can deliver up to 8,000 watts (240 VAC input) or 4,800 watts (125 VAC input). The S‐ POE‐4BAY‐PWR PoE subsystem, which is included in the S8‐POE‐4BAY‐UGK, S4‐POE‐4BAY‐ UGK, and S3‐POE‐4BAY‐UGK upgrade kits, can be installed on the S8, S4, or S3 chassis. See Figure 1‐1 on page 1‐2 for an example of the S‐POE‐4BAY‐PWR PoE subsystem installed on an S3 chassis. • S‐POE‐8BAY‐PWR — An eight‐bay PoE subsystem for up to eight S‐POE‐PS power supplies, which can deliver up to 16,000 watts (240 VAC input) or 9,600 watts (125 VAC input). The S‐ POE‐8BAY‐PWR PoE subsystem, which is included in the S8‐POE‐8BAY‐UGK upgrade kit, can be installed on the S8 chassis only. See Figure 1‐2 on page 1‐3. Besides the PoE subsystem, each PoE upgrade kit contains a bus bar, which connects the PoE subsystem to the backplane of the S‐Series chassis, and all other hardware necessary for upgrading the S‐Series chassis. For a complete list of the hardware included in each upgrade kit, refer to Table 2‐1 on page 2‐2. Enterasys S-Series PoE Subsystem Upgrade Installation Guide 1-1... -
Page 20: S3 Chassis With S-Poe-4Bay-Pwr Poe Subsystem
Features Figure 1-1 S3 Chassis with S-POE-4BAY-PWR PoE Subsystem 1 Four-bay PoE subsystem (S-POE-4BAY- 2 S3 Chassis PWR) 1-2 Introduction... -
Page 21: S8 Chassis With S-Poe-8Bay-Pwr Poe Subsystem
1 Eight-bay PoE subsystem (S-POE-8BAY- 2 S8 Chassis PWR) For the PoE upgrade process, see Chapter 2, Installing the PoE Upgrade Kit. For specifications and compliance information for the PoE subsystems, see Appendix A, Specifications and Regulatory Compliance. Note: The PoE upgrade kit does not include S-POE-PS power supplies. You must order the S-POE-PS power supplies separately. For information about the S‐POE‐PS power supply, see the Enterasys S‐Series Chassis Hardware Installation Guide included with your S‐Series chassis. Enterasys S-Series PoE Subsystem Upgrade Installation Guide 1-3... -
Page 22: Precautions
Starkstromverteilung und den entsprechenden Sicherheitsvorkehrungen vertraut ist. Warning: Install the Enterasys S-Series chassis in a Restricted Access Location only. Access to the equipment by users must be restricted through the use of a tool or lock and key or other means of security and is controlled by the authority responsible for the location. -
Page 23: Chapter 2: Installing The Poe Upgrade Kit
For more information about: Refer to page... Required Tools Unpacking the PoE Upgrade Kit Preparing for Installation Installing the PoE Subsystem and the Bus Bar Required Tools • ESD wrist strap (included in the PoE upgrade kit) • Phillips screwdriver (#2) • Hex wrench (3/16”) • Torque wrench Enterasys S-Series PoE Subsystem Upgrade Installation Guide 2-1... -
Page 24: Unpacking The Poe Upgrade Kit
To unpack the S‐Series PoE upgrade kit: Open the box and remove the packing material protecting the contents of the kit. Save the shipping box and packing materials in the event the upgrade kit must be reshipped. Verify the contents of each carton and compare the contents shipped with those listed in Table 2‐1. Perform a visual inspection of the PoE subsystem and bus bar for any signs of physical damage. If there are any signs of damage, DO NOT install the PoE upgrade kit; instead, contact Enterasys Networks. Refer to “Getting Help” on page xv for details. Table 2-1 Hardware Contents of PoE Upgrade Kit Item Quantity PoE subsystem (S-POE-4BAY-PWR or S-POE-8BAY-PWR) Bus bar (S3-POE-BUSBAR, S4-POE-BUSBAR, or S8-POE-BUSBAR) ESD wrist strap EMI gasket Flat head screws Nylon spacers, .375”... -
Page 25: Preparing For Installation
Elektrischer Gefahrenhinweis: Das Gerät muss von der Stromzufuhr getrennt sein, um den Schutz vor Stromschlägen gewährleisten zu können. Remove all S‐AC‐PS power supplies from the S‐Series chassis. Remove all modules from the S‐Series chassis. If the S‐Series chassis is mounted in a rack, you must remove the S‐Series chassis from the rack. Put on the ESD wrist strap and attach it to the ESD grounding receptacle on the S‐Series chassis. See Figure 2‐1. Figure 2-1 ESD Grounding Receptacle (S3 Chassis Example) Enterasys S-Series PoE Subsystem Upgrade Installation Guide 2-3... -
Page 26: Installing The Poe Subsystem And The Bus Bar
Personal vorgenommen werden. Note: For correct functionality of the system, you must use the hardware supplied with the PoE upgrade kit. Remove the small PoE cover in the back left corner on the top panel of the S‐Series chassis. See Figure 2‐2. This cover and its four screws will not be reinstalled. Figure 2-2 Removing the PoE Cover from the S-Series Chassis 2-4 Installing the PoE Upgrade Kit... -
Page 27: Installing The Emi Gasket On The S-Series Chassis
Installing the PoE Subsystem and the Bus Bar Install the EMI gasket on the S‐Series chassis. Remove the adhesive backing from the gasket. Place the gasket carefully in the recessed area of the S‐Series chassis. See Figure 2‐3. Ensure that the gasket does not bulge inside the opening on the S‐Series chassis. Figure 2-3 Installing the EMI Gasket on the S-Series Chassis Enterasys S-Series PoE Subsystem Upgrade Installation Guide 2-5... -
Page 28: Placing The Poe Subsystem On The S-Series Chassis (S3 Chassis/S-Poe-4Bay-Pwr Example)
2‐4. Note: If the PoE subsystem’s ribbon cable is hanging outside the PoE subsystem, feed the cable through the opening in the S-Series chassis before setting the PoE subsystem down on the S- Series chassis. Ensure that you do not pinch the ribbon cable. -
Page 29: Securing The Poe Subsystem To The S-Series Chassis (S3 Chassis/S-Poe-4Bay-Pwr Example)
Installing the PoE Subsystem and the Bus Bar Secure the PoE subsystem to the S‐Series chassis with the eight flat head screws—four screws on each side—included in the upgrade kit. See Figure 2‐5. Figure 2-5 Securing the PoE Subsystem to the S-Series Chassis (S3 Chassis/S-POE- 4BAY-PWR Example) Enterasys S-Series PoE Subsystem Upgrade Installation Guide 2-7... -
Page 30: Removing The Rear Panels From The S-Series Chassis And The Poe Subsystem (S3 Chassis/S-Poe- 4Bay-Pwr Example)
22 screws S-POE-4BAY-PWR 14 screws S-POE-8BAY-PWR 18 screws (see Figure 2-7 for the location of the screws) Set the panels and screws aside for reinstallation at the end of this procedure. Figure 2-6 Removing the Rear Panels from the S-Series Chassis and the PoE Subsystem (S3 Chassis/S-POE-4BAY-PWR Example) 2-8 Installing the PoE Upgrade Kit... -
Page 31: Location Of Rear Panel Screws On The S-Poe-8Bay-Pwr Poe Subsystem
Installing the PoE Subsystem and the Bus Bar Figure 2-7 Location of Rear Panel Screws on the S-POE-8BAY-PWR PoE Subsystem Enterasys S-Series PoE Subsystem Upgrade Installation Guide 2-9... -
Page 32: Attaching The Poe Subsystem Ribbon Cable To The S-Series Chassis Backplane
Attach the PoE subsystem’s ribbon cable to the connector on the S‐Series chassis backplane. See Figure 2‐8. Figure 2-8 Attaching the PoE Subsystem Ribbon Cable to the S-Series Chassis Backplane PoE subsystem ribbon cable S-Series chassis backplane connector Note: Ensure that the ribbon cable is connected properly to the backplane connector as misalignment can occur. -
Page 33: Installing The Nylon Washers And Spacers On The S3 Chassis Backplane Studs
Installing the Nylon Washers and Spacers on the S3 Chassis Backplane Studs Backplane stud Nylon spacer (.375”) Nylon washer (.100”) Note: The .100” washers, which are included only with the S3-POE-4BAY-UGK upgrade kit, apply to the S3 upgrade only. Enterasys S-Series PoE Subsystem Upgrade Installation Guide 2-11... -
Page 34: Installing The Nylon Spacers On The S4 And S8 Chassis Backplane Studs (S8 Chassis Example)
Installing the PoE Subsystem and the Bus Bar – S4 and S8 chassis: Only a nylon spacer (.375”) goes on each backplane stud. See Figure 2‐10. Figure 2-10 Installing the Nylon Spacers on the S4 and S8 Chassis Backplane Studs (S8 Chassis Example) Backplane stud Nylon spacer (.375”) Note: The .100” nylon washers used in the S3 upgrade are not used in the S4 and S8 upgrade and are not included in the S4-POE-4BAY-UGK, S8-POE-4BAY-UGK, and S8-POE-8BAY-UGK upgrade kits. -
Page 35: Poe Connectors On The Bus Bar (S3-Poe-Busbar Example)
Installing the PoE Subsystem and the Bus Bar Install the bus bar. Orient the bus bar so that the pairs of PoE connectors, which extend from the bus bar, face the backplane of the S‐Series chassis. See Figure 2‐11. Figure 2-11 PoE Connectors on the Bus Bar (S3-POE-BUSBAR Example) Bus bar PoE connectors must face the backplane of the S-Series chassis Enterasys S-Series PoE Subsystem Upgrade Installation Guide 2-13... -
Page 36: Inserting The Bus Bar Through The S Chassis Into The Poe Subsystem
Installing the PoE Subsystem and the Bus Bar b. Insert the terminating end of the bus bar (that is, the end with the screw holes) up through the opening between the S‐Series chassis and the PoE subsystem. See Figure 2‐12. ‐ If you are installing the S‐POE‐4BAY‐PWR PoE subsystem, you must place the terminating end of the bus bar in front of the PoE subsystem’s jumper plates. See Figure 2‐13 on page 2‐15. ‐ If you are installing the S‐POE‐8BAY‐PWR PoE subsystem on an S8 chassis, you must sandwich the terminating end of the bus bar between the PoE subsystem’s jumper plates. See Figure 2‐14 on page 2‐15. Figure 2-12 Inserting the Bus Bar through the S Chassis into the PoE Subsystem (S3 Chassis/S-POE-4BAY-PWR Example) PoE subsystem jumper plates Bus bar... -
Page 37: Bus Bar Placed In Front Of The S-Poe-4Bay-Pwr Jumper Plates
Bus Bar Placed in Front of the S-POE-4BAY-PWR Jumper Plates Bus bar S-POE-4BAY-PWR jumper plates Figure 2-14 S8 Bus Bar Sandwiched between the S-POE-8BAY-PWR Jumper Plates S-POE-8BAY-PWR front jumper plates S-POE-8BAY-PWR rear jumper plates S8 bus bar Enterasys S-Series PoE Subsystem Upgrade Installation Guide 2-15... -
Page 38: Securing The Bus Bar To The Backplane Studs With Hex Nuts (S3 Chassis/S-Poe-4Bay-Pwr Example)
Installing the PoE Subsystem and the Bus Bar 10. Secure the bus bar to the backplane studs with the hex nuts provided in the upgrade kit. See Figure 2‐15. Figure 2-15 Securing the Bus Bar to the Backplane Studs with Hex Nuts (S3 Chassis/S- POE-4BAY-PWR Example) Note: Torque the hex nuts to 9 inch pounds. 2-16 Installing the PoE Upgrade Kit... -
Page 39: Securing The Bus Bar To The Poe Subsystem's Jumper Plates
Repeat steps a–c for each of the remaining three screw holes. Figure 2-16 Securing the Bus Bar to the PoE Subsystem’s Jumper Plates (S3 Chassis/S- POE-4BAY-PWR Example) Flat washers Socket head cap screws Belleville washers (concave side facing the flat washers) Enterasys S-Series PoE Subsystem Upgrade Installation Guide 2-17... -
Page 40: Reinstalling The Rear Panels Of The S Chassis And The Poe Subsystem
Installing the PoE Subsystem and the Bus Bar Reinstall the rear panels of the S‐Series chassis and the PoE subsystem. See Figure 2‐17. Note: Torque the flat head screws for the rear panels of both the S-Series chassis and the PoE subsystem to 9 inch pounds. Figure 2-17 Reinstalling the Rear Panels of the S Chassis and the PoE Subsystem (S3 Chassis/S-POE-4BAY-PWR Example) You can now install the upgraded S‐Series chassis in an equipment rack in a restricted access ... -
Page 41: Chapter 3: Installing The Poe Power Supplies
Table 3-1 Contents of S-POE-PS Power Supply Carton Item Quantity S-POE-PS power supply For USA shipments: NEMA Power Cord 5-20, C19, R/A, SHLD Type of power cord is dependent on country of installation. NOTICE Card Enterasys S-Series PoE Subsystem Upgrade Installation Guide 3-1... -
Page 42: Installing The S-Poe-Ps Power Supplies In The Poe Subsystem
Installing the S-POE-PS Power Supplies in the PoE Subsystem Installing the S-POE-PS Power Supplies in the PoE Subsystem You must install the PoE subsystem on the S‐Series chassis before installing the S‐POE‐PS power supplies in the PoE subsystem. To install the S‐POE‐PS power supplies in the PoE subsystem: Open the faceplate of the S‐POE‐PS power supply by releasing the spring clip on the lower left of the faceplate. Align the power supply with bay 1 (labelled PS1), then slide the S‐POE‐PS power supply forward until the S‐POE‐PS power supply is plugged into the subsystem connector and is completely inside the bay. See Figure 3‐1. The power supply’s faceplate will close as the power supply plugs into the subsystem connector. If you encounter significant resistance before the S‐POE‐PS power supply reaches the end of its travel, remove and reinsert the power supply. Figure 3-1 Inserting the S-POE-PS Power Supply in the PoE Subsystem Close the power supply’s faceplate completely against the spring clip on the power supply. -
Page 43: Removing A Cover Plate From The Poe Subsystem
Installing the S-POE-PS Power Supplies in the PoE Subsystem If you are installing more than one power supply, remove the coverplates from the applicable number of power supply slots by unscrewing the captive screw that attaches each coverplate to the PoE subsystem. See Figure 3‐2. Keep the coverplates in the event you need to remove the power supplies. The PoE subsystem ships without a cover on bay 1. Figure 3-2 Removing a Cover Plate from the PoE Subsystem Repeat steps 1 through 3 for each additional power supply. Enterasys S-Series PoE Subsystem Upgrade Installation Guide 3-3... - Page 44 Installing the S-POE-PS Power Supplies in the PoE Subsystem 3-4 Installing the PoE Power Supplies...
-
Page 45: Appendix A: Specifications And Regulatory Compliance
Item Specification Electrical Input Frequency 50 to 60 Hz Input (Voltage/Current) at Output 100 to 125 Vac: 15 A at 1200 watts Power 200 to 240 Vac: 11 A at 2000 watts Enterasys S-Series PoE Subsystem Upgrade Installation Guide A-1... -
Page 46: Torque Values
Torque Values Table A-2 S-POE-PS Power Supply Specifications (continued) Item Specification Physical Dimensions 4.22 cm x 10.16 cm x 35.18 cm (1.66” x 4.00” x 13.85”) Weight 2.1 kg (4.6 lbs) Torque Values Table A‐3 describes the recommended torque values to use when installing standard threaded fastener machine screws and bolts. Table A-3 Recommended Torque Values by Screw Size Screw Size Torque in Pounds Bit Size... - Page 47 Chassis Bonding and Grounding This appendix provides chassis bonding and grounding instructions for the S‐Series chassis. Installing the chassis as described in this appendix meets the protective earth grounding requirements of the National Electrical Code (NEC) UL 60950 and IEC 60950 standards. However, in some cases it is necessary to use an alternative grounding method at installation sites that must meet the Telcordia GR‐1089 Section 9, Bonding and Grounding Requirements, or national deviations. To meet these requirements, use the four tapped holes located on the rear‐center side of the chassis. These holes meet the hole grounding bolt pattern requirements. Alternate grounding requirements when a connection is needed between the chassis and the enclosure metalwork, a nearby point on the Central Office (CO) Ground system, or earth ground. The connection is made using one or more grounding wires (as needed) fabricated from an 8 AWG mm) stranded copper wire. To fabricate and install a grounding wire, proceed as follows: Cut an 8 AWG (6 mm) stranded‐copper wire to length, long enough to reach from the grounding location of the chassis to the selected grounding location on the CO Ground, earth ground, or enclosure metalwork. Install a listed two‐hole compression‐type connector on both ends of the grounding wire. Apply a suitable antioxidant to the chassis grounding location and unpainted surface grounding location on the CO Ground or enclosure metalwork. Connect one ground cable two‐hole connector to the chassis using two of the 1/4‐20 screws shipped with the chassis. Connect the two‐hole connector at the other end of the cable to the CO Ground or enclosure metalwork using user‐supplied screws. Torque screws to 67 inch pounds (± 5%). National Deviations: • In Norway, Sweden, and Finland, the same procedure can be used for a permanent protective earth ground connection as required by their national deviation to IEC 60950, Section 5.1.7. • In Denmark, the chassis must be installed utilizing a Type B grounded plug. Enterasys S-Series PoE Subsystem Upgrade Installation Guide B-1...
