Left Side View

1

Vent

This enables airflow to prevent the computer from overheating.
To prevent your computer from overheating make sure nothing blocks the vent/fan
intake while the computer is in use.

External Monitor (VGA) Port

Connect an external VGA monitor to this port to allow dual video or simulta-
neous display on the LCD and external VGA monitor (see
on page 3 - 9).
9
2 3 4 5
Overheating
8
1.
6 7
2.
3.
4.
5.
6.
7.
8.
9.
"Display Devices"
Left Side View 1 - 11
Introduction
Figure 1 - 4
Left Side View
Vent
External Monitor
(VGA) Port
S-Video Out Port
RJ-11 Phone Jack
RJ-45 LAN Jack
2 * USB 2.0 Ports
Mini-IEEE 1394
Port
PC Card Slot
PC Card Eject
Button
1
