Ventilation
The Notebook features the ventilation to dissipate the
system's operating heat. Do not block or obstruct it during
operation.
Right-side Stand
Move this stand (together with the left one) to adjust the typing
angle. If a high speed CPU is installed on the system,
erecting the stands on both sides will be necessary for
heat dissipation during operation (Figure 1-13).
PC Card Sockets
2.5" Hard Disk Drive
Speaker-out
3.5" Floppy Disk Drive
Figure 1-12
Figure 1-13
Ventilation
Line-in
Microphone-in
Right -side Stand
