CPU Core Voltage
Locate the 8-pole DIP Switch to set the correct configuration for
CPU core voltage.
CPU Core Voltage
1.8 V
2.0 V
2.1 V
2.35 V
2.45 V
2.8 V
2.9 V
3.3 V
Accessing DIP Switch
1. Turn the system power off.
2. Turn the Notebook over.
3. Remove the CPU cover. Locate the 8-pole DIP Switch to set
the configuration (Figure 2-6).
1
2
3
On
Off
Off
On
On
Off
On
On
On
On
On
On
On
On
On
On
On
On
On
On
On
On
On
On
Figure 2-6
4
5
6
Off
Off
Off
Off
Off
Off
Off
Off
Off
On
Off
Off
On
On
Off
On
On
On
On
On
On
On
On
On
7
8
Off
Off
Off
Off
Off
Off
Off
Off
Off
Off
Off
Off
On
Off
On
On
