Right-side View
PC Card Sockets
One Type III or two Type II PC cards may be used. Both
sockets will expand the system capabilities when a PC card is
inserted. To eject the PC card, press the appropriate eject
button (Figure 2-17).
2.5" Hard Disk Drive
The 2.5" hard disk drive is designed to be removable.
It
accepts any 2.5" IDE hard disk drive with a height of 12.7mm
or less. Refer to Chapter 2: Operation for more information.
3.5" Floppy Diskette Drive
The Notebook comes standard with a 1.44MB floppy drive
installed. You may press the button on its top-right side for
diskette ejection. The floppy disk module can be replaced
with optional accessory, such as the secondary 2.5"/3.0" hard
disk drive or Zip drive (Refer to Chapter 2: Operation for more
information).
Speaker-out Jack
Headphone and speakers can be attached to the system
through this jack.
Line-in Jack
External audio source can be fed into the Notebook through
this jack.
Microphone-in Jack
Use this jack to connect a microphone to the system.
