Components Menu

Item
COM Ports COM A I/O
Settings
COM B I/O
Settings
Mode Setting
For COM B
DMA Setting
For Fast IR
LPT Port Port Address
Port Definition
DMA Setting
For ECP Mode
EPP Type
Setting/Option
None
COM1, 3F8, IRQ4
COM2, 2F8, IRQ3
COM3, 3E8, IRQ4
COM4, 2E8, IRQ3
None
COM1, 3F8, IRQ4
COM2, 2F8, IRQ3
COM3, 3E8, IRQ4
COM4, 2E8, IRQ3
Normal (16550A)
IrDA (HPSIR)
ASK IR
FAST IR
DMA 0
DMA 1
DMA 3
None
LPT1, Addr 378h,
IRQ7
LPT2, Addr 278h,
IRQ5
LPT3, Addr 3BCh,
IRQ7
Standard AT (Centronics)
Bidirectional (PS-2)
Enhanced Parallel (EPP)
Extended Capabilities (ECP)
DMA 1
DMA 3
EPP 1.7
EPP 1.9
Chapter 3: BIOS Utilities
Function
Specify the COM A
configuration.
Specify the COM B
configuration.
Define the COM B
hardware.
Specify the Fast IR DMA
configuration.
Specify the LPT port and
IRQ configuration.
Specify the ECP DMA
configuration.
Specify the EPP type.
3-13
