Using Cd-Rom - EUROCOM 8500 DeskNote User Manual

Chapter 2: Operation 2-17

Using CD-ROM

The Notebook comes standard with a removable 5.25" CD-ROM
module. It is labeled drive D: and may be used as a boot device if
properly set.
Do not disassemble the CD-ROM module. Only certified
technicians should perform repairs to the CD-ROM module.
To insert a CD, press the Eject Button and place the CD on the
Disc Tray label-side facing up. Push the CD tray in, and you are
ready to get started. The Busy Indicator will light up while data is
accessed or audio is playing. When system power is unexpectedly
interrupted, insert an instrument such as a straightened paper clip
into the Emergency Eject Hole to manually eject the tray (Figure
2-14).
Disc Tray
Eject Button
Emergency Eject Hole
Busy Indicator
Figure 2-14
