Using PC Card Sockets

The Notebook provides system expansion capabilities with two PC
card sockets (previously referred to as PCMCIA). PC cards to be
inserted can be LAN, fax/modem, communication devices, or
expanded memory. Both sockets support 5V/3.3V 16-bit PC cards
and 3.3V 32-bit PC cards (referred to as CardBus). PC cards have
three types: Type I measures 3.3mm thick; Type II 5.0mm; and
Type III 10.5mm.
The PC card sockets on the right-side panel support one Type III
card (equivalent to two Type II cards) and are ZV (Zoomed Video)
capable (Figure 2-17).
Eject button for socket B
Socket B
Socket A
Eject button for socket A
Figure 2-17
Chapter 2: Operation 2-21
