Parallel Modes - EUROCOM 3400 UltraLite User Manual

Firmware: setup – advanced menu
1
2
3
4
5

Parallel Modes

Most newer printers recommend
ECP or Bidirectional mode.
6
7
8
4 – 10
M
ODE
(A M >
DVANCED ENU
I/O D C > S B)
EVICE ONFIGURATION ERIAL PORT
There are several modes available
if you set the serial port B to "En-
abled". Make sure the mode you
choose is supported by the device
with which you want to communi-
cate. Fast IR (FIR), as the name im-
plies, is the most powerful option
followed by IrDA (standard) and
then ASK.
P
ARALLEL PORT
(A M >I/O D C
DVANCED ENU EVICE ONFIGURATION
If you don't plan to use this port,
you can set this line to "Disabled"
to save power. The default setting
is "Enabled".
M
ODE
(A M > I/O D C
DVANCED ENU EVICE ONFIGURATION
> P P )
ARALLEL ORT
There are several modes available
once you set this port to "Enabled":
ECP (Extended)
EPP (Enhanced)
Output only
Bi-directional
You should check your parallel
device's documentation to see
which one it can use.
)
