T S P
HE ETUP ROGRAM
The Phoenix Setup program tells the system how to configure itself and
manage basic features and subsystems (e.g. port configuration and power
management).
E S
NTERING ETUP
To enter Setup, turn on the com-
puter and press F2 during the
POST. The prompt seen in Fig. 3 –
1 is usually present for a few sec-
onds after you turn on the system.
If you get a "Keyboard Error" (usu-
ally because you pressed F2 too
quickly) just press F2 again.
If the computer is already on, reboot
using the Ctrl + Alt + Delete
combination and then hold down
F2. Setup's main menu will appear.
S S
ETUP CREENS
The Setup interface looks like a
"windows" screen:
Along the top of the screen is a
menu bar with six (6) menu head-
ings. When you select a heading, a
new screen appears. Scroll through
the features listed on each screen
to make changes to Setup.
Instructions on how to navigate
each screen are in the box along the
bottom of the screen. If these tools
are confusing, press F1 to call up a
General Help screen. Then use the
arrow keys to scroll up or down this
page.
