User This allows you to fill in the
Cylinders, Heads and Sectors/
Track fields. It automatically
calculates "size" based on this
information. The numbers for
all these fields should be
printed on the hard disk itself,
or in its accompanying docu-
mentation.
Note: For future use, and as a precaution,
make a record the hard disk's original con-
figuration.
M -S T
ULTI ECTOR RANSFERS
(M M >P M )
AIN ENU RIMARY ASTER
Select the number of sectors in
each block that can be transferred
together. The "Auto" Type setting
shows the optimum number.
LBA M C
ODE ONTROL
(M M >P M )
AIN ENU RIMARY ASTER
If your hard disk is larger than
528MB (unformatted capacity),
enable this control. The "Auto"
Type setting enables this setting if
the disk is large enough.
32 B I/O
IT
(M M >P M )
AIN ENU RIMARY ASTER
Most new hard disks can support
this higher rate. If yours can't, the
"Enabled" setting may slow down
the system.
T M & U DMA M
RANSFER ODE LTRA
(M M >P M )
AIN ENU RIMARY ASTER
These settings allow you to choose
among various modes used for data
transfers. "Auto" Type setting se-
lects the best modes for your HDD.
S M
ECONDARY ASTER
(M
This line shows the second IDE
device, either a CD/DVD-ROM an
LS-120 or nothing (if you've in-
stalled the floppy drive in the De-
vice Bay).
Refer to Chapter 3: Device Bay for
more on how to configure these
devices.
Firmware: setup – main menu
LBA Warning
If you enable LBA mode for a
particular HDD, be sure to en-
able it each time you use the
same hard disk. If you don't you
ODE
may encounter read/write er-
rors.
When to Use LBA
The "standard" or ATA mode of
M )
AIN ENU
"seeing" HDDs is inadequate for
drives larger than 528MB. LBA
mode corrects this and allows for
hard disks up to 128GB.
ATA and LBA modes overlap. So
if LBA mode is not activated when
an HDD is first formatted, sections
may not be readable under the
LBA system. (This does not mat-
ter with 528 MB or smaller HDDs.)
If you're using an HDD not format-
ted using LBA mode, do not use
the "Auto" setting.
