Device Bay: FDD
1
FDD Removal Warning
2
Do not remove the FDD module
from the port or Device bay
3
while it is active. This could dam-
age the system, the FDD or re-
sult in data loss and/or corrup-
4
tion.
5
FDD S
TATUS
F . 3 - 4
IG
The LED flashes whenever
6
the FDD is in use, either in the de-
vice bay or connected by the
adapter cable.
7
8
D B
EVICE AY WITH
F . 3 - 5
IG
1. FDD
2. eject button
3 – 10
FDD (F
The FDD can work equally well
in either the internal or external
position. It doesn't need to be "set
up" attached or installed when you
boot-up. The system won't "look"
for it until told to "look" at drive
A:.
I
NDICATOR
FDD
) M
LOPPY ODULE
D B I
EVICE AY NSTALLATION
We recommend that you put the
system into Suspend mode, Save
to Disk, or better yet, turn it off
first. Then slide the FDD module
into the bay until it "clicks" into
place.
(Follow the instructions on page 3-3.)
D B R
EVICE AY EMOVAL
If you must remove the FDD mod-
ule during a session, do it carefully
and either return the module to
the Device bay at a later time, or
turn the system OFF. Other drive
modules cannot replace the FDD
during the same session.
2
1
