External Connection - EUROCOM 3400 UltraLite User Manual

E C
XTERNAL ONNECTION
If the Device bay is occupied (e.g. with a CD-ROM), you can connect
the FDD to the parallel port with its proprietary cable: Attach the
cable to the FDD module first, then attach the other end of the cable to
the port.
3
2
Cable Warning
The FDD+adapter combination
cable only works with the FDD
module.
If it's connected to the port, the
cable must also be connected to
the FDD module or the system
may halt.
FDD P
1
1. FDD module
2. FDD to adapter
3. (parallel) port
Disk Care
Refer to page 1-11 for more on how
to take care of your disks
Device Bay: FDD
