EXAMPLE NETWORKS
C S O
ONFIGURING YSTEM
To configure System Options and Information, press 2 at the Security Menu. By default, all system
options are enabled by default, which is acceptable for this network.
Press "2" at the System Options and Information Menu. This is where we will configure the system
information for SITE1. Enter SITE1 as the system name, and df8sfds33 as the system secret:
System Information Menu:
1) System Name
2) System Password
3) System Secret
Select function from above or <RET> for previous menu?
Return to the Main Menu, and save your configuration changes. Reboot SITE1 to activate your
changes.
C SITE2
ONFIGURE
The initial configurations of SITE1 and SITE2 are similar. For the initial configuration of SITE2,
duplicate the steps found in the section titled,
C SITE2 O
ONFIGURING
For this example, we only need IP routing enabled. Unlike the SITE1, we do not need to enable IP
routing for the SITE2. IP routing is enabled as a default for SITE2. We do need to configure IP
interface information.
C IP I
ONFIGURING THE NTERFACE
To configure the IP interface information for SITE2, use the same instructions provided for SITE1
(page 66), with the following exceptions:
IP Interfaces for SITE2:
• Configure the LAN Network Interface
The IP address is 128.3.3.1.
A D SITE1
DDING EVICE
Follow the instructions used for configuring device SITE1
• Device Name: SITE1
• Dial-Out Phone Number: 918105551234
• CHAP Secret: df8sfds33
74 CyberSWITCH
I
PTIONS AND NFORMATION
is "SITE1"
is ""
is "df8sds33"
PTIONS
I
NFORMATION
Configure SITE1 (page 65).
(page 68) with the following exceptions:
