C S
ONFIGURING THE ECURITY
To begin, press 1 at the Security Menu, and the Security Level Menu will be displayed. To enable
Device Level Security, press 2.
C S
ONFIGURING THE YSTEM
The default configuration for System Options is all security options enabled, which is acceptable
for this network. No System Information or Administration Sessions are required. Therefore, no
changes are necessary.
C D
ONFIGURING THE EVICE
Press 3 at the Security Menu, and the Device Level Database Menu will be displayed. To enable the
On-node Device Database, press 1 and follow the on-screen instructions.
To add the remote devices, press 2 (On-node Device entries). Press 1 to configure the information for
our first device, Monterey. You will be prompted for the device name, followed by the Device Table
Menu:
Device Name? Monterey
Device Table Menu: (Device = "Monterey")
1) ISDN
2) Frame Relay
3) X.25
4) Authentication
5) IP
6) IPX
7) AppleTalk
8) Bridging
9) Compression
Select function from above or <RET> for previous menu: 1
Select 1, ISDN. The ISDN Menu will display the preconfigured default values:
Device ISDN Menu: (Device = "Monterey")
1) ISDN Line Protocol
2) Base Data Rate
3) Initial Data Rate
4) Maximum Data Rate
5) Dial Out Phone Number(s)
6) Subaddress
7) Profile Name
8) H0 Call Support
Select function from above or <RET> for previous menu: 1
We do not want to use the default ISDN Line Protocol of PPP. Press 1 to configure this device's
ISDN line protocol. The device Monterey uses HDLC protocol, so we will press 2:
L
EVEL
O I
PTIONS AND NFORMATION
L D
EVEL ATABASES
"PPP (Point to Point Protocol)"
"64000 bps"
"64000 bps"
"128000 bps"
""
""
"Default_Profile"
DISABLED
IP R N
OUTING ETWORK WITH
Configure the CyberSWITCH
Workgroup Remote Access Switch
R B D
EMOTE RIDGE EVICES
