EXAMPLE NETWORKS
Press 5 to enter the first dial out number. A phone number must be defined for each remote device
that will be dialed. This number includes any prefix digits, area codes, or extensions as required to
dial the destination device. It is possible to specify two phone numbers for the remote device. For
this example, we will only be entering one phone number, 913135553232, which is the phone
number for SITE2.
After all of the ISDN configuration has been completed, the ISDN Configuration Menu will be
displayed as follows:
Device ISDN Menu: (Device = "SITE2")
1) ISDN Line Protocol
2) Base Data Rate
3) Initial Data Rate
4) Maximum Data Rate
5) Dial Out Phone Number(s) "913135553232"
6) Subaddress
7) Profile Name
8) H0 Call Support
Select function from above or <RET> for previous menu?
Return to the Device Table Menu.
At the Device Table Menu, press 4 to enter the authentication information needed for this device.
The authentication information needed for each device depends on the device type.
For device "SITE2", because we will be configuring CHAP security, we opt to configure a CHAP
secret (ikcd98s). After the secret has been entered, the Device Authentication Configuration Menu
will appear as follows:
Device Authentication Menu: (Device = "SITE2")
PPP:
1) PAP Password
2) CHAP Secret
3) Outbound Authentication
4) User Level Authentication
IP Host (RFC 1294):
5) IP Host Id
HDLC Bridge:
6) Bridge Ethernet Address
7) Bridge Password
ISDN:
8) Calling Line Id(s)
Select function from above or <RET> for previous menu:
Again, return to the Device Table Menu.
Next, press 5 to enter the IP Information for device SITE2. SITE2 uses an unnumbered link, so we
will enter the IP address as 0.0.0.0.
70 CyberSWITCH
"PPP (Point to Point Protocol)"
"64000 bps"
"64000 bps"
"384000 bps"
""
"Default_Profile"
DISABLED
""
"ikcd98s"
ENABLED
DISABLED
""
""
""
""
