EXAMPLE NETWORKS
C C
ONFIGURE THE
Note: The software should have already been installed and you should see the system prompt
before proceeding with these steps.
Using the detailed instructions for these steps found in the
complete the following configuration steps.
Start the CFGEDIT program
Select physical resources
Select to add a resource
Select Switch type to be 4ESS
Select to add a line
Enter "Line1" as the line name
Select slot 1, port 1
Add Data Links
Repeat "Add Data Links" for second Data Link
Repeat "Select to add a line" for each additional line
The following sections provide instructions for completing the remaining configuration steps.
C C
ONFIGURING THE
To begin the configuration of the system options, press 2 at the Main Menu. The following options
menu will then be displayed:
Options Menu:
1) Bridging
2) IP
3) IPX Routing
4) AppleTalk
5) SNMP
6) PPP
7) Call Control Options
8) Default Line Protocol
9) Log Options
10) Compression
Select function from above or <RET> for previous menu:
For this example, we only need IP routing enabled. IP routing is already enabled as fault, so no
change is necessary.
For this example, the only other IP information we need to configure is for IP interfaces. No static
routes are needed because Router 1 supports RIP, which eliminates the need to manually configure
a static route. The next section will provide the instructions needed to configure the necessary IP
interfaces.
36 CyberSWITCH
SWITCH
YBER
Choose Auto TEI Negotiation
Enter SPID Value
Enter Directory Number for Data Link
Enter Maximum Number of Digits to Verify
SWITCH O
YBER PTIONS
Simple Remote Bridging chapter,
