SmartSwitch 9000
9M426-02
User's Guide
9032531-01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FPIM 02 FPIM-02 and is the answer not in the manual?

Questions and answers

Related Manuals for Cabletron Systems FPIM 02 FPIM-02

Summary of Contents for Cabletron Systems FPIM 02 FPIM-02

  • Page 1 SmartSwitch 9000 9M426-02 User’s Guide 9032531-01...
  • Page 3 Printed in the United States of America Order Number: 9032531-01 LANVIEW is a registered trademark and SmartSwitch is a trademark of Cabletron Systems, Inc. i960 microprocessor is a registered trademark of Intel Corp. Ethernet is a trademark of Xerox Corporation.

  • Page 4: Fcc Notice

    Notice FCC Notice This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules.

  • Page 5: Declaration Of Conformity

    ____________________________________________________ Title Rochester, NH, USA ____________________________________________________ Location ADDENDUM 89/336/EEC 73/23/EEC Cabletron Systems, Inc. 35 Industrial Way PO Box 5005 Rochester, NH 03867 Mr. J. Solari Cabletron Systems Limited Nexus House, Newbury Business Park London Road, Newbury Berkshire RG13 2PZ, England...
  • Page 6 Notice...

  • Page 7: Table Of Contents

    Installing the SmartSwitch 9000 Module Unpacking the Module... 2-1 User Accessible Components ... 2-1 Installing the Module into the SmartSwitch 9000 Chassis... 2-4 The Reset Switch ... 2-6 Chapter 3 Operation System Management Buses ... 3-1 SMB-1 Bus ... 3-1 SMB-10 Bus ...
  • Page 8 Contents...

  • Page 9: Chapter 1 Introduction

    Introduction The 9M426-02 SmartSwitch Module shown in Figure 1-1, is a three port switch module with two front panel HSIM interfaces and one INB-2 backplane interface. With the proper HSIM, this module may be used as an ATM uplink for the SmartSwitch 9000 chassis.
  • Page 10 For a complete list of supported MIBs, refer to the release notes provided in the 9M426-02 package. LANVIEW LEDs The 9M426-02 uses LANVIEW – the Cabletron Systems built-in visual diagnostic and status monitoring system. With LANVIEW LEDs, you can quickly identify the device, port, and physical layer status at a glance.
  • Page 11 Introduction 9M426-02 Figure 1-1. The 9M426-02 Module...

  • Page 12: Related Manuals

    • A description of any action(s) already taken to resolve the problem (e.g., changing mode switches, rebooting the unit, etc.) • The serial and revision numbers of all involved Cabletron Systems products in the network • A description of your network environment (layout, cable type, etc.) •...

  • Page 13: Chapter 2 Installing The Smartswitch 9000 Module

    2. Remove the module from the plastic bag. Observe all precautions to prevent damage from Electrostatic Discharge (ESD). 3. Carefully examine the module, checking for damage. If any damage exists, DO NOT install the module. Contact Cabletron Systems Technical Support immediately. User Accessible Components Figure 2-1 shows the various components that are accessible to the user.
  • Page 14 Installing the SmartSwitch 9000 Module 1 2 3 4 5 6 7 8 DIP Switch Local DRAM Socket Figure 2-1. User Accessible Components SMB-1 PROM i960 Processor Boot PROM Flash SIMM Socket...
  • Page 15 An eight position DIP switch is located on the module card as shown in Figure 2-1. The function of the switches are listed in Table 2-1. See the Cautions at the end of this table. Switch Function Password NVRAM Force BootP...

  • Page 16: Installing The Module Into The Smartswitch 9000 Chassis

    Installing the SmartSwitch 9000 Module Installing the Module into the SmartSwitch 9000 Chassis To install the SmartSwitch 9000 module, follow the steps below: The INB Terminator Modules must be installed on the rear of the chassis before powering NOTE up this module. Refer to the INB Terminator Modules Installation Guide for information and installation procedure.
  • Page 17 Metal Back-Panel Ensure that the circuit card is between the card guides. Lock down the top and bottom plastic tabs at the same time, applying even pressure. Figure 2-2. Installing the 9M426-02 Module Installing the SmartSwitch 9000 Module F L N K F L N K F L N K F L N K...

  • Page 18: The Reset Switch

    Installing the SmartSwitch 9000 Module The Reset Switch The Reset switch is located under the top plastic tab as shown in Figure 2-3. Use the reset switch to reset the module’s processor, shutdown (power down) the module, and/or restart the module.

  • Page 19: Chapter 3 Operation

    Operation The 9M426-02 FDDI SmartSwitch Module is a three port switch module with two front panel HSIM interfaces and one INB-2 backplane interface. This module, with the proper HSIM, may be used for an FDDI, ATM, WAN and other high-speed connectivity for the SmartSwitch 9000 chassis.

  • Page 20: System Diagnostic Controller

    SecureFast Switch The SmartSwitch ASIC is a hardware based switch design that is the key building block of the SmartSwitch 9000. All filtering/forwarding decisions are made in hardware as opposed to software as in traditional switches. This custom hardware allows the SmartSwitch ASIC to process over 150K frames per second.

  • Page 21: I960 Core

    INB backplane, and LAN/WAN interfaces on the front panel of SmartSwitch 9000 modules. The SmartSwitch ASIC can operate in two modes: as a traditional switch, or as a SecureFast Switch (SFS). When operating in traditional switch mode, it makes filtering/forwarding decisions based on Destination Address (DA), with standard IEEE 802.1d learning.
  • Page 22 Operation...

  • Page 23: Lanview Leds

    LANVIEW LEDs The front panel LANVIEW LEDs indicate the status of the module and may be used as an aid in troubleshooting. Shown in Figure 4-1 is the LANVIEW LEDs of the 9M426-02 module. System Status FNB Transmit FNB Receive 9 9 M M 4 4 2 2 6 6 - - 0 0 2 2 S S M M B B C C P P U U...
  • Page 24 LANVIEW LEDs The functions of the two System Status LEDs, System Management Bus (SMB) and the CPU, are listed in Table 4-1. LED Color Green Yellow Yellow (flashing) Yellow/Green Red (Flashing) The functions of the INB receive LED are listed in Table 4-2. LED Color Green (Flashing) Green...

  • Page 25: Chapter 5 Specifications

    Specifications Technical Specifications Intel i960 RISC based microprocessor Memory 4 Meg. Flash Memory (expandable to 8 Meg.) 16 Meg. DRAM (expandable to 32 Meg.) Network Interface Cabletron HSIMs Safety It is the responsibility of the person who sells the system to which the module will be a part to ensure that the total system meets allowed limits of conducted and radiated emissions.

  • Page 26: Service

    Specifications • EMC requirements of: EN 50082-1 IEC 801-2 ESD IEC 801-3 Radiated susceptibility IEC 801-4 EFT Service MTBF (MHBK-217E) MTTR Physical Dimensions 35.0 D x 44.0 H x 6.0 W centimeters (13.8 D x 17.4 H x 2.4 W inches) Weight Unit: Shipping:...
