A
R
LAN D
DD
EMOTE
EVICES
From the On-node Device Entries Menu, select Add. Enter the device name for the Tampa site, which
is tampabr. Select Authentication, and add the Tampa site's PAP password, which is tbpswd. Accept
defaults for ISDN and IPX information.
From the Device Table Menu, select Bridging. Enter the IPX Remote LAN Network Number of 0128,
which is the external network number of the Remote LAN at the Tampa site. Be sure make calls field
is disabled, since Remote LAN does not as yet support this feature.
Note:
In our example, we could have also accepted the default option for the IPX Network
Number, NONE, since the remote LAN has no servers locally attached to it. In this case, the
Remote LAN's network address would default to 0128, the external network number we
will configure for the
chapter, Network Interface Background Information.
The bridging options for tampabr should now look like the following:
Device Bridge Menu:
1) IP (Sub)Network Number
2) Bridging
3) Make calls for bridge data
4) IPX Remote LAN Network Number
5) IPX Spoofing Options
6) AppleTalk Network Number
Enter selection or press <RET> for previous menu:
The configuration of device tampabr is complete. Return to the On-node Device Entries Menu, and
add the device orlandobr in a similar fashion. After devices tampabr and orlandobr have been
configured, return to the Main Menu.
C
S
ONFIGURE
YSTEM
Next, we must configure bridging and routing information, which falls under the Options category.
To begin its configuration, press 2 at the Main Menu. For this example, we will enable bridging,
enable IPX routing, and configure the necessary IPX routing information.
E
B
NABLE
RIDGING
1.
Select Options from the Main Menu.
2.
Select Bridging.
3.
Follow screen prompts to insure that bridging is enabled (to support Remote LAN).
E
IPX R
NABLE
OUTING
1.
Select Options from the Main Menu.
Remote LAN
(Device = "tampabr")
O
PTIONS
Configure IPX Routing: Masternet (Detroit)
interface. For more details, refer to the Configuring IPX
NONE
ENABLED
DISABLED
0128
Workgroup Remote Access Switch
IPX R
N
OUTING
ETWORK
87
