EXAMPLE NETWORKS
The interactive LAN interface session should be similar to the following:
1) LAN
2) WAN
3) WAN (Direct Host)
4) WAN (RLAN)
5) WAN (UnNumbered)
Select function from above or <RET> for previous menu: 1
INTERFACE NAME or <RET> to cancel? SanFran
Enter the IP Address in dotted decimal notation
or <RET> to cancel? 128.1.1.1
Enter the number of significant bits for the Subnet Mask
[default = 16]?
Enter the packet encapsulation type 1) for ETHERNET 2) for SNAP
[default = ETHERNET]?
Enter the MTU size in bytes [default = 1500]?
Transmit Broadcast Address:
1) 128.1.255.255
2) 128.1.0.0
3) 255.255.255.255
4) 0.0.0.0
5) Specify Explicitly
Enter a Transmit Broadcast Address from the above menu [default = 1]? <RET>
RIP Send Control:
1) Do Not Send.
2) RIP Version 1.
3) RIP Version 1 Compatibility.
4) RIP Version 2.
Enter a RIP Send Control from the above menu [default = 2]?
(
RIP Receive Control:
1) Do Not Receive.
2) RIP Version 1 Only.
3) RIP Version 2 Only.
4) RIP Version 1 or Version 2.
Enter a RIP Receive Control from the above menu [default = 4]? <RET>
RIP Respond Control:
1) Do Not Respond.
2) RIP Version 1 Only.
3) RIP Version 2 Only.
4) RIP Version 1 or Version 2.
Enter a RIP Respond Control from the above menu [default = 4]? <RET>
RIP Version 2 Authentication Control:
1) No Authentication.
2) Simple Password.
Enter a RIP Authentication Control from the above menu [default = 1]? <RET>
38 CyberSWITCH
