EXAMPLE NETWORKS
four calls/connections running in parallel). Configure a dial-out number for the Dallas site, which is:
912143339999. We will not use the remaining parameters (subaddress, profile name or HO support)
for this example. Return to the Device ISDN menu (following), and then return to the Device Table
Menu:
Device ISDN Menu: (Device = "dallasnet")
1) ISDN Line Protocol
2) Base Data Rate
3) Initial Data Rate
4) Maximum Data Rate
5) Dial Out Phone Number(s)
6) Subaddress
7) Profile Name
8) H0 Call Support
Select function from above or <RET> for previous menu:
Authentication Information
From the Device Table Menu, select Authentication. Add the Dallas site's PAP password, which is
dnpswd.
IPX Information
From the Device Table Menu, select IPX. From this configuration menu, insure that IPX routing and
Make calls for IPX data are enabled. You may then enable IPXWAN protocol:
Device IPX Menu:
1) IPX Routing
2) Make calls for IPX data
3) IPXWAN Protocol
4) Routing Protocol
5) Spoofing Options
Select function from above or <RET> for previous menu? 3
Use the IPXWAN protocol for this device (Y or N)
Next, select Routing Protocol. For this example, we will use the triggered RIP/SAP protocol, and
select a WAN Peer Type of ACTIVE:
IPX Device Routing Protocol
1)
None
2)
RIP/SAP
3)
Triggered RIP/SAP
Enter selection or press <RET> for previous menu [default=None}: 3
1)
Active
2)
Passive
Triggered RIP/SAP WAN Peer type [default=ACTIVE]:
Finally, there is no need to change the default Spoofing Options. Return to the Device Table Menu.
86
CyberSWITCH
"PPP (Point to Point Protocol)"
"64000 bps"
"64000 bps"
"256000 bps"
"912143339999"
""
"Default_Profile"
DISABLED
(Device = "dallasnet")
ENABLED
ENABLED
DISABLED
None
<RET>
[default = N] ? Y
1
