C. Consumables and Durables

1. Copier

No. Part name
1 Cleaner blade (drum cleaner
assembly)
2 Drum cleaner scoop-up sheet
3 Side seal, front (drum cleaner
assembly)
4 Side seal, rear (drum cleaner
assembly)
5 No. 2 scoop-up sheet (pre-
cleaning sensor)
6 Grid plate (primary charging
assembly)
7 Primary charging assembly
cleaning pad, upper
8 Primary charging assembly
cleaning pad, lower
9 Primary charging wire, 100V
Primary charging wire, 120/
230V
10 Scanning lamp
11 Manual feeder pickup roller
12 Manual feeder feed roller
13 Manual feeder separation
roller
14 Attraction roller scraper
15 Waste toner case (6 pc/box)
16 Post-cleaning charging wire
Post-cleaning charging wire
17 Fixing cleaning belt (upper,
lower)
18 Drum cleaner end felt, front
19 Drum cleaner end felt, rear
20 No. 2 cleaning blade
21 Fixing upper roller
22 Oil applying felt
23 Y starter developer
24 M starter developer
25 C starter developer
CHAPTER 1 MAINTENANCE AND INSPECTION
Part number Q'ty
FB4-4677 1
FF5-3993 1
FF5-8392 1
FF5-8393 1
FG6-1046 1
FB4-5117 1
FF2-3552 1
FF2-3551 1
FY3-0030 1
FY3-0040 1
FH7-3349 1
FF5-4327 2
FF5-4331 1
FF2-4710 1
FF5-8427 1
FY9-7006 1
FY3-0030 1
FY3-0040 1
FB4-4543 1
FF5-2246 1
FF5-2247 1
FB2-0421 2
FB4-4484 1
FF5-9084 1
F42-3132 1
F42-3133 1
F42-3122 1
F42-3123 1
F42-3112 1
F42-3113 1
As of
Life Remarks
(copies)
20,000 Simultaneously with
photosensitive drum.
20,000 Simultaneously with
cleaning blade.
20,000 Simultaneously with
cleaning blade.
20,000 Simultaneously with
cleaning blade.
20,000 Simltaneously with cleaning
blade.
20,000 For high temperature/high
humidity, 15,000.
20,000 For high temperature/high
humidity, 15,000.
20,000
20,000 For high temperature/high
20,000 humidity, 15,000.
25,000
25,000 Manual feeder counter
reading.
25,000 Manual feeder counter
reading.
25,000 Manual feeder counter
reading.
25,000
25,000 By user.
20,000 100V
20,000 120/230V
25,000
40,000 Simultaneously with
40,000 cleaning blade.
40,000 20,000 per edge.
40,000 Or, 1 yr.
40,000 20,000 per side.
40,000
40,000 120V UL only.
40,000
40,000 120V UL only.
40,000
40,000 120V UL only.
