Chapter 1 Maintenance and Inspection

1.1 Periodically Replaced Parts

1.1.1 Overview
iR2016J / iR2016 / iR2020 / / iR2016i / iR2020i
The machine has parts that must be replaced on a periodical basis to ensure a specific level of functional performance. (The loss of the function of any of these parts
will significantly affect the machine performance, regardless of the presence/absence of external changes or damage.)
If possible, schedule the replacement so that it coincides with a scheduled service visit.
The timing of replacement may vary depending on the site environment or user habit.
1.1.2 Reader Unit
iR2016J / iR2016 / iR2020 / / iR2016i / iR2020i
The reader unit does not have parts that require periodical replacement.
1.1.3 Printer Unit
iR2016J / iR2016 / iR2020 / / iR2016i / iR2020i
The printer unit does not have parts that require periodical replacement.

1.2 Durables and Consumables

1.2.1 Overview
iR2016J / iR2016 / iR2020 / / iR2016i / iR2020i
The machine has parts that may require replacement once or more during the period of product warranty because of wear or damage. Replace them as needed by
referring to their indicated estimated lives.
- Checking the Timing of Replacement
Use the following service mode item to check the timing of replacement:
#COUNTER > DRBL-1
- FX-UNIT: Fixing Unit
- TR-ROLL: Transfer roller
- DV-UNIT-C: Developing unit
- M-PU-RL: Manual feed pickup roller
- M-SP-PD: Manual feed separation pad
1.2.2 Reader Unit
iR2016J / iR2016 / iR2020 / / iR2016i / iR2020i
The reader unit does not have parts that are classified as durables.
1.2.3 Printer Unit
iR2016J / iR2016 / iR2020 / / iR2016i / iR2020i
Ref.
Parts name
[1]
Manual feed pickup roller
[2]
Manual feed separation pad
[3]
Devrloping unit
[4]
Transfer roller
[5]
Fixing unit (120V)
Fixing unit (230V)
The value is the mean value collected from the results of evaluation. The parts number may change because of changes in design.
T-1-1
Parts No.
Q'ty
FL2-3202-000
1
FL2-3201-000
1
FM2-3286-000
1
FC6-4313-000
1
FM2-3345-000
1
FM2-3352-000
1
As of Aug. 2005
Life
Remarks
150K
150K
150K
150K
150K
150K
Chapter 1
0011-0421
0011-0422
0011-0423
0011-0424
0011-0425
0011-0426
1
