ADuC812
the gain calibration coefficient is divided into ADCGAINH (6 bits)
and ADCGAINL (8 bits).The offset calibration coefficient compen-
sates for dc offset errors in both the ADC and the input signal.
Increasing the offset coefficient compensates for positive offset,
and effectively pushes the ADC Transfer Function DOWN.
Decreasing the offset coefficient compensates for negative offset,
and effectively pushes the ADC Transfer Function UP. The
maximum offset that can be compensated is typically ± 5% of
, which equates to typically ±125 mV with a 2.5 V reference.
V
REF
Similarly, the gain calibration coefficient compensates for dc
gain errors in both the ADC and the input signal.
Increasing the gain coefficient compensates for a smaller analog
input signal range and scales the ADC Transfer Function UP,
effectively increasing the slope of the transfer function. Decreas-
ing the gain coefficient, compensates for a larger analog input
signal range and scales the ADC Transfer Function DOWN,
effectively decreasing the slope of the transfer function. The
maximum analog input signal range for which the gain coeffi-
cient can compensate is 1.025 × V
range is 0.975 × V which equates to typically ± 2.5% of the
REF
reference voltage.

Calibration

Each ADuC812 is calibrated in the factory prior to shipping and
the offset and gain calibration coefficients are stored in a hidden
area of FLASH/EE memory. Each time the ADuC812 powers
up, an internal power-on configuration routine, copies these
coefficients into the offset and gain calibration registers in
the SFR area.
The MicroConverter ADC accuracy may vary from system to
system due to board layout, grounding, clock speed, etc. To get
the best ADC accuracy in your system, you should perform
the software calibration routine described in the technical
note uC005 available from the MicroConverter home page
(www.analog.com/microconverter).

NONVOLATILE FLASH MEMORY

Flash Memory Overview

The ADuC812 incorporates Flash memory technology on-chip
to provide the user with a nonvolatile, in-circuit reprogram-
mable, code and data memory space.
Flash/EE memory is a relatively recent type of nonvolatile memory
technology and is based on a single transistor cell architecture.
This technology is basically an outgrowth of EPROM technol-
ogy and was developed through the late 1980s. Flash/EE memory
takes the flexible in-circuit reprogrammable features of
EEPROM and combines them with the space efficient/density
features of EPROM (see Figure 14).
Because Flash/EE technology is based on a single transistor cell
architecture, a Flash memory array, like EPROM, can be imple-
mented to achieve the space efficiencies or memory densities
required by a given design.
Like EEPROM, Flash memory can be programmed in-system at
a byte level, although it must first be erased; the erase being
performed in page blocks. Thus, Flash memory is often and
more correctly referred to as Flash/EE memory.
Overall, Flash/EE memory represents a step closer towards
the ideal memory device that includes nonvolatility, in-circuit
programmability, high density and low cost. Incorporated in
the ADuC812, Flash/EE memory technology allows the user to
and the minimum input
REF
EPROM
TECHNOLOGY
SPACE EFFICIENT/
DENSITY
FLASH/EE MEMORY
TECHNOLOGY
update program code space in-circuit without the need to
replace one-time programmable (OTP) devices at remote
operating nodes.

Flash/EE Memory and the ADuC812

The ADuC812 provides two arrays of Flash/EE memory for
user applications. 8K bytes of Flash/EE Program space are
provided on-chip to facilitate code execution without any
external discrete ROM device requirements. The program
memory can be programmed using conventional third party
memory programmers. This array can also be programmed
in-circuit, using the serial download mode provided.
A 640-Byte Flash/EE Data Memory space is also provided on-chip.
This may be used by the user as a general purpose nonvolatile
scratchpad area. User access to this area is via a group of six
SFRs.

ADuC812 Flash/EE Memory Reliability

The Flash/EE Program and Data Memory arrays on the ADuC812
are fully qualified for two key Flash/EE memory characteristics,
namely Flash/EE Memory Cycling Endurance and Flash/EE
Memory Data Retention.
Endurance quantifies the ability of the Flash/EE memory to be
cycled through many Program, Read, and Erase cycles. In real
terms, a single endurance cycle is composed of four independent,
sequential events. These events are defined as:
a. Initial Page Erase Sequence
b. Read/Verify Sequence
c. Byte Program Sequence
d. Second Read/Verify Sequence
In reliability qualification, every byte in both the program and
data Flash/EE memory is cycled from 00 hex to FFhex until a
first fail is recorded signifying the endurance limit of the on-chip
Flash/EE memory.
As indicated in the specification pages of this data sheet, the
ADuC812 Flash/EE Memory Endurance qualification has been
carried out in accordance with JEDEC Specification A117 over
the industrial temperature range of –40°C, +25°C, and +85°C.
The results allow the specification of a minimum endurance figure
over supply and temperature of 10,000 cycles, with an endurance
figure of 50,000 cycles being typical of operation at 25°C.
Retention quantifies the ability of the Flash/EE memory to retain
its programmed data over time. Again, the ADuC812 has been
qualified in accordance with the formal JEDEC Retention Life-
time Specification (A117) at a specific junction temperature
(T = 55°C). As part of this qualification procedure, the Flash/EE
J
memory is cycled to its specified endurance limit described
above, before data retention is characterized. This means
that the Flash/EE memory is guaranteed to retain its data for
its full specified retention lifetime every time the Flash/EE
memory is reprogrammed.
EEPROM
TECHNOLOGY
IN-CIRCUIT
REPROGRAMMABLE
A single Flash/EE
Memory
Endurance Cycle
