6. Dispose of the battery according to local ordinance.
7. Remove the new lithium battery from its package, and, being careful to observe the
correct polarity, insert it in the battery socket.
Note: You will need to run the BIOS setup to restore the system configuration settings to the
RTC.

Replacing the Power Supply

Caution: The power supply is not hot-swappable. Before removing or replacing the power supply,
you must first take the server out of service, turn off all peripheral devices connected to
the system, turn off the system by pressing the power button, and unplug the AC power
cord from the system or wall outlet.
The power supply can be replaced if it fails or if one of the fans that is integrated into it
fails. To replace the power supply, follow these steps:
1. Disconnect all power cables.
2. Lift the power supply to disengage it from the latch (see letter "A" in
and remove the power supply by sliding it out (see letter "B" in
®
Intel Server System SR1600UR Service Guide

Figure 76. Replacing the Backup Battery

AF002865
Figure 77)
Figure 77).
87
