To configure SLP:
1. Enter the following fields.
Port
(view only)
Name
(view only)
Device
(view only)
SLP Login
SLP Password/
Retype Password
SLP Status/Info
Outlet Status
Environmental
Status
Infeed Status
System Info
SLP Commands
Restart SLP
Control Outlet
2. Click the Apply button.
Device Port – Sensorsoft Device
Devices made by Sensorsoft are used to monitor environmental conditions.
To access the Sensorsoft device:
1. In the Connected to field above the IP Settings section of the Device Ports – Settings page,
select Sensorsoft.
2. Click the Device Commands link.
SecureLinx SLC User Guide
Displays the port number.
Displays the port name.
Displays the device type.
User ID for logging into the SLP.
Password for logging into the SLP.
Note: If there is an SLP and an SLP Expansion chassis, the SLP is Tower A and
the Expansion chassis is Tower B.
For Tower A or Tower B, select All Outlets or Single Outlet to view the status of
all outlets or a single outlet of the SLP. If you select Single Outlet, enter a value of
1-8 for the SLP8 or 1-16 for the SLP16.
Click the Outlet Status link to see the status of the selected outlet(s).
Click the link to view the environmental status (e.g., temperature and humidity) of
the SLP.
Click the link to view the status of the data the SLP is receiving.
Click the link to see system information pertaining to the SLP.
To restart the SLP, select the checkbox.
For Tower A or Tower B, select All Outlets or Single Outlet and the number of the
outlet to be controlled (1-8 for the SLP8 or 1-16 for the SLP16) and select the
command for the outlet (No Action, Power On, Power Off, Cycle Power). No Action is
the default.
Figure 8-7 shows the page that displays.
