Location for Save,
Restore, or Manage
Preserve
Configuration after
Restore
3. Click the Apply button.
Note: If you selected an option that forces a reboot (restore configuration, update
firmware, or reset factory defaults), the SLC automatically reboots at the end of the
process.
To manage configuration files:
The Manage option on the Firmware & Configurations page allows you to view all configurations
saved to the selected location and delete any of the configurations. This feature is available for the
local disk, NFS, CIFS Share, USB port, and PC Card locations.
1. On the Firmware & Configurations page, click the Manage link in the Location for Save,
Restore, or Manage section of the page.
SecureLinx SLC User Guide
If you selected to save or restore a configuration, select one of the following
options:
 Local Disk – Saved Configurations: If restoring, select a saved
configuration from the drop-down list.
FTP Server : The FTP server specified in the FTP/SFTP/TFTP section. If

you select this option, select FTP or SFTP to transfer the configuration
file.
 NFS Mounted Directory: Local directory of the NFS server for mounting
files.
CIFS Share – Saved Configurations: If restoring, select a saved

configuration from the drop-down list.
 PC Card: If a PC Card Compact Flash is loaded into one of the PC Card
slots on the front of the SLC, and properly mounted (see
the configuration can be saved to or restored from this location. If you
select this option, select the slot (upper or lower) in which the PC Card
Compact Flash is mounted, and then select a saved configuration from
the drop-down list.
 USB: If a USB device is loaded into the USB port on the front of the SLC
and properly mounted, the configuration can be saved to or restored from
this location (see 10: USB Port).
 HTTPS: This option allows a configuration to be uploaded to the local disk
for restore or saved via HTTPS.
 Manage: The Manage option allows you to view and delete all
configurations saved to the selected location. This feature is available for
the local disk, NFS, CIFS Share, USB port, and PC Card locations. (See
next procedure).
Allows the user to keep a subset of the current configuration after restoring a
configuration or resetting to factory defaults.
Select the checkbox for each part of the current configuration you want to
keep, for example, Networking, Services, or Device Ports.
Figure 13-2
13: Maintenance
9: PC
shows the page that displays.
Cards),
