Figure 12-6 Radius Page - Lantronix SecureLinx SLC8 User Manual

Figure 12-6 RADIUS Page
2. Enter the following fields.
Enable RADIUS
RADIUS Server #1
Server #1 Port
Server #1 Secret
SecureLinx SLC User Guide
Displays selected if you enabled this method on the User Authentication page. If
you want to set up this authentication method but not enable it immediately, clear
the checkbox.
Note: You can enable RADIUS here or on the first User Authentication page. If
you enable RADIUS here, it automatically displays at the end of the order of
precedence on the User Authentication page.
IP address or hostname of the primary RADIUS server. This RADIUS server may
be a proxy for SecurID.
SecurID is a two-factor authentication method based on the user's SecurID token
and pin number. The SecurID token displays a string of digits called a token code
that changes once a minute (some tokens are set to change codes every 30
seconds).
Number of the TCP port on the RADIUS server used for the RADIUS service. If
you do not specify an optional port, the SLC uses the default RADIUS port (1812).
Text that serves as a shared secret between a RADIUS client and the server
(SLC). The shared secret is used to encrypt a password sent between the client
and the server. May have up to 128 characters.
12: User Authentication
152
