Loading Paper

The following explains the procedure for loading paper in the cassette and the MP tray.
Loading Paper into the Cassette
The standard cassette holds up to 500 sheets of A4 or smaller plain paper (80 g/m²).
The following paper sizes are supported: 8-1/2 × 14" (Legal), Oficio II, 8-1/2 × 11" (Letter), Executive, Statement, A4, B5,
A5, A6, B6, Folio, 216 × 340 mm, 16K, ISO B5, Envelope DL, Oufuku Hagaki, Envelope C5 and Custom.
IMPORTANT You should not use inkjet printer paper or any paper with a special surface coating. (Such papers may
cause paper jams or other faults.)
When using media types other than plain paper (such as recycled or colored paper), always specify the media type
setting. (Refer to Cassette (1 to 5) Type (Setting the cassette paper type) on page 4-32.) The cassettes can hold
paper with weights up to 120 g/m².
Do not load thick paper that is heavier than 120 g/m² in the cassettes. Use the multi purpose tray for paper that is
heavier than 120 g/m².
Note A6 can only be used in cassette 1.
Cassette
1
Fan the media (paper/transparencies), then tap it on a level surface
to avoid media jams or skewed printing.
2
Pull the cassette completely out of the machine.
IMPORTANT When pulling the cassette out of the machine,
ensure it is supported and does not fall out.
3
(On FS-2100D/FS-2100DN only) Press the bottom plate down until it
Bottom Plate
locks.
